Datasensing SSZ/0P-1A Sensors
Datasensing
$77.74
The Datasensing SSZ/0P-1A Sensors are robust photoelectric sensors designed for precise detection tasks. Featuring an M18 receiver with a nominal sensing distance of 14 meters, these sensors are equipped with a PNP L/D selectable output and an axial optic position. The sensors are built to withstand harsh environments, offering complete protection against electrical damages and an IP67 protection degree. They are suitable for a wide range of applications, with a switching frequency of 250Hz and a rapid response time of 2ms. The sensors operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 30mA.
Constructed with a durable nickel-plated brass housing and a 2-meter PVC cable, the sensors are designed to endure temperatures from -25°C to +70°C without freezing. They include essential features such as short-circuit and reverse polarity protection, impulsive overvoltage protection, and LED infrared emission at 880nm. The sensors are also equipped with a yellow LED status indicator for easy monitoring.
With approvals from CE and cULus, and compliance with EMC compatibility standards (EN 60947-5-2), these sensors are reliable and safe for industrial use. They come with supplied accessories, including M18 x 1 nuts, and are designed to handle shocks and vibrations as per IEC standards. The Datasensing SSZ/0P-1A Sensors are an ideal choice for applications requiring high precision and reliability.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
