Datasensing ST 18-C Sensors
Datasensing
$2.72
The Datasensing ST 18-C Sensors are high-performance inductive proximity sensors designed for industrial applications. Featuring a robust M18 standard no-flush mount design, these sensors offer a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm. They are equipped with a 2m PVC cable for easy installation and connectivity.
Constructed with durable nickel-plated brass housing, the sensors are suitable for harsh environments, boasting an IP67 mechanical protection rating. They are versatile, supporting both NPN and PNP output types with NO/NC output functions, and are capable of handling a load current of up to 200mA. The sensors operate efficiently within a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and an output voltage drop of ? 1.8V at 100mA.
The ST 18-C Sensors are designed with user-friendly features such as a yellow LED indicator for output state and short-circuit and reverse polarity protection. They are also immune to weld fields and have a high switching frequency of 1kHz, ensuring rapid response times of 0.5ms. With a tightening torque of 20Nm and supplied with two M18x1 nuts, these sensors are easy to mount and secure.
Certified by CE, cULus, ECOLAB, and DIVERSEY, the Datasensing ST 18-C Sensors are reliable and compliant with industry standards, making them an ideal choice for various industrial applications requiring precise and dependable proximity sensing.
- Nominal sensing distance:
- 8mm
- Operanting distance:
- 0 6,48mm
- Standard target:
- 24x24mm FE360
- Correction Factor:
- copper: 0,4 0,5 / aluminium: 0,4 0,6 / brass: 0,5 0,7 / stainelss steel: 0,7 1,05
- Repeat Accuracy:
- < 3% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- < 10%
- Description:
- M18 standard no-flush mount
- Functions:
- Proximity
- Output type:
- NPN/PNP
- Output Function:
- NO/NC
- Switching frequency:
- 1kHz
- Response time:
- 0,5
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- 200mA
- Output voltage drop:
- ? 1,8V @100mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- ?100kHz
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Dimensions:
- Ø18x79
- Housing Material:
- Nickel-plated brass
- Connections:
- 2m PVC Cable
- Active Head Material:
- LCP
- Tightening torque:
- 20Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus ECOLAB DIVERSEY
- Supplied Accessories:
- 2 nuts M18x1
- Dimensions:
- Ø18 / L = 79mm
- Operating Temperature:
- -25°C +60°C
- Mechanical Protection:
- IP67
