Datasensing UK1C/G6-0ASY Sensors
Datasensing
$388.14
The Datasensing UK1C/G6-0ASY Sensors are designed for precision and reliability in various industrial applications. These sensors feature a nominal sensing distance of 900mm and utilize a diffuse reflection function principle, ensuring accurate detection with a beam angle of 10° ± 2°. The sensors offer both digital programmable outputs and current or voltage analogue outputs, providing flexibility for different operational needs.
Equipped with an adjustable hysteresis function, these sensors are ideal for level-specific applications, featuring programmable double digital outputs. The working area can be easily adjusted using the Teach-in button, allowing for quick setup and operation. The multifunction LED indicator provides clear feedback on output type, adjustment procedures, and NO/NC selection, along with reverse analog output slope indication.
Built with a robust PBT housing, the sensors are designed to withstand harsh environments, with an IP67 degree of protection and operating temperatures ranging from -20°C to +70°C. They are equipped with short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring durability and safety. The sensors come with a 2m PVC cable for easy installation and are approved by CE and cULus standards, ensuring compliance with international safety and performance regulations.
- Nominal sensing distance:
- 900mm
- Thermal drift of Sr:
- ±2%
- Repeat Accuracy:
- 0,50%
- Beam angle:
- 10° ± 2°
- Resolution:
- ?3mm
- Sensitivity adjustment:
- Teach-in button
- Hysteresis:
- 1%
- thermal compensation:
- Yes
- Minimum sensing distance (blind zone):
- 100mm
- Linearity error:
- 1%
- Function Principle:
- Diffuse reflection
- Output type:
- PNP + 4...20mA
- Output Function:
- NO/NC + positive/negative slope
- Switching frequency:
- 4Hz
- Response time:
- 500ms
- Operating Voltage:
- 10 - 30Vdc
- No-Load supply current:
- ?50mA
- Load current:
- 100mA
- Leakage current:
- 10?A @ 30Vcc
- Output voltage drop:
- 2,2Vmax. @ IL=100 mA
- Max ripple content:
- 5%
- LED indicators:
- green: echo - yellow: output
- Time delay before availability:
- ?300ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 110g
- Housing Material:
- PBT housing
- Connections:
- 2m PVC Cable
- Tightening torque:
- 1Nm
- Storage temperature:
- - 35°C + 80° C without freeze
- Transducer Frequency:
- 300kHz
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- IEC EN60947-5-2 / 7.4
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M18x1, 2 washers Ø 18
- Mechanical Protection:
- IP67
