Datasensing VK2/C0-2H Sensors

The Datasensing VK2/C0-2H Sensors are high-performance inductive sensors designed for precision and reliability. Featuring an M18 unshielded NC connection with an M12 plug cable exit, these sensors are ideal for various industrial applications. With a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm, they ensure accurate proximity detection. The sensors are equipped with a multivoltage range of 20 to 253 Vac, making them versatile for different power requirements. Built to withstand harsh environments, the VK2/C0-2H sensors boast an IP67 protection degree, ensuring resistance to dust and water ingress. The housing is made from durable nickel-plated brass, while the active head is constructed from PBT, providing robust mechanical protection. The sensors are designed to operate efficiently within a temperature range of -25°C to +70°C. Key features include a TRIAC output type with an NC output function, a switching frequency of 25Hz, and a load current capacity of 5 to 300mA. The sensors also feature a yellow LED indicator for output state, ensuring easy monitoring. With a repeat accuracy of less than 5% and a thermal drift of Sr under 10%, these sensors deliver consistent performance. The VK2/C0-2H sensors are compliant with CE and UR approvals and meet EMC compatibility standards as per IEC 60947-5-2. They are also designed to withstand shocks and vibrations according to IEC 60068-2-6 and IEC 60068-2-27 standards. Supplied with two M18x1 nuts, these sensors are ready for easy installation and reliable operation in demanding industrial settings.
