Dynapar 115163-0001 Assembly Kit for HA/HC/HR526 Encoder Series
Dynapar
$255.15
The Dynapar 115163-0001 is an assembly kit containing the insert component for HA/HC/HR526 encoder series installations, enabling precise hub-shaft coupling for incremental optical encoders in demanding industrial environments. This kit supports Series H20-style encoders with resolutions up to 2540 PPR, 5-26 VDC input power, and output options including open collector, push-pull, or differential line drivers, with quadrature phasing and optional index pulse. It features dual-row bearing design for reliability, NEMA 12/IP54 enclosure (upgradable to NEMA 4/IP66 with seals), shaft loading up to 80 lbs radial/axial, and operation from 0 to +70°C (extended to +85°C), suitable for motor feedback, conveyor speed measurement, and factory automation applications.
Documentation
- Technical Datasheet: https://www.dynapar.com/hubfs/downloads/H20_DS_701879-0002.pdf
- Product Manual: https://www.dynapar.com/downloads/product_manuals/h20-hubshaft-manual.pdf
- H20 Hub-Shaft Encoder Page: https://www.dynapar.com/en/products-and-solutions/incremental-encoders/h20hubshaft
- Encoder Accessories Catalog: https://www.dynapar.com/en/products-and-solutions/accessories
