Dynapar DS616-BS60 Hengstler Japan Encoder
Dynapar
$1,827.90
The Dynapar DS616-BS60 is a heavy-duty incremental optical encoder from Hengstler Japan, featuring a 60 mm frame size with a hub shaft configuration for reliable speed, position, and motion feedback in industrial applications. It supports RS422 electrical interface with quadrature A/B outputs, suitable for high-resolution tasks in factory automation, off-highway vehicles, and conveyor systems. Key characteristics include a tapered solid or hub shaft (10 mm diameter), shaft loading capacity of 5 lb axial and 20 lb radial, and robust environmental ratings such as -15°C to +120°C operating temperature, 100G shock, 10G vibration (10-2000 Hz), and IP40 enclosure per EN 61326-1.
Documentation
- Technical Datasheet: https://www.dynapar.com/hubfs/downloads/DS616-BS60_datasheet.pdf
- Product Manual: https://www.dynapar.com/manuals/DS616_series_manual.pdf
- Installation Guide: https://www.dynapar.com/installation/DS616_encoders.pdf
- CAD Drawings: https://www.dynapar.com/cad/DS616-BS60_3D_model.dwg
