Dynapar HS35IQ01024H7P71R1 Encoder
Dynapar
$1,881.90
The Dynapar HS35IQ01024H7P71R1 is a heavy-duty incremental hollow-shaft optical encoder from the HS35iQ series, featuring 1024 PPR resolution, 1-inch bore size, and slotted tether kit with cover for secure mounting on shafts with tolerances of +0.0000/-0.0005 and runout under 0.002 TIR. It provides differential ABZ outputs via 7272 line driver (40 mA sink/source), with PulseIQ technology for specific fault indication including cable integrity (for 7272 options), shaft slip, overspeed, over-temperature, insufficient voltage, and electronic failure; input power is 5-26 VDC at 80 mA max (250 mA max including loads), frequency response up to 200 kHz, and IP67 enclosure (IP64 above 5000 RPM) with 400G shock and 20G vibration resistance across -40°C to +100°C extended temperature range. Typical applications include mill-duty and heavy plant environments for position/speed feedback in factory automation, off-highway vehicles, and oil & gas equipment.
Documentation
- Technical Datasheet: https://www.dynapar.com/hubfs/uploadedFiles/_site_root/Products_and_Solutions/HS35iQ-Datasheet-703409-0001.pdf?hsLang=en
- Encoder Installation Manual: https://www.dynapar.com/hubfs/downloads/HS35R_IM_702761_1_X.pdf?hsLang=en
- Product Series Page: https://www.dynapar.com/products_and_solutions/hs35iq-hollow-shaft-encoder
- HS35iQ Series Datasheet: https://www.dynapar.com/ecatalog/encoder-products/product-details/HS35IQ01024H7P71R1
