Leuze E4-V1-BZ1 Industrial Sensor System
Leuze
$74.00
The E4-V1-BZ1 is a precision industrial sensor engineered for demanding automation applications. Featuring IP66 protection and wide operating temperature range, it delivers reliable performance in manufacturing, logistics, and process control environments.
Technical Specifications:
Protection rating: IP66 (dust-protected, water-resistant)
Technical Documentation:
Complete technical specifications, dimensional drawings, wiring diagrams, and safety documentation are available on the Leuze website at https://www.leuze.com/en-us/usa/products (search model E4-V1-BZ1). CAD models in STEP and EPLAN formats available for download to streamline machine design and panel layout.
- Series:
- E4
- Suitable for:
- Tower light elements of the E4 series
- Type of signaling:
- Acoustic
- Supply voltage UB:
- 24 V, DC, 10 %
- Current consumption, max.:
- 39 mA, Switch-on current: 7A
- Design:
- Cylindrical
- Dimension ( x L):
- 40 mm x 71 mm
- Housing material:
- Plastic
- Net weight:
- 43 g
- Type of fastening:
- Bayonet system
- Operational controls:
- DIP switch
- Function of the operational control:
- Selection of tone type
- Ambient temperature, operation:
- -30 ... 60 C
- Degree of protection:
- IP 66
- Approvals:
- c UL US
- Tone type:
- Continuous or pulse tone
- Sound pressure:
- 80 dB
- Number of tones:
- 1 Piece(s)
- Customs tariff number:
- 85318070
- ECLASS 5.1.4:
- 27371237
- ECLASS 8.0:
- 27371237
- ECLASS 9.0:
- 27371237
- ECLASS 10.0:
- 27371237
- ECLASS 11.0:
- 27371237
- ECLASS 12.0:
- 27371237
- ECLASS 13.0:
- 27371237
- ECLASS 14.0:
- 27371237
- ECLASS 15.0:
- 27371237
- ETIM 5.0:
- EC001261
- ETIM 6.0:
- EC001261
- ETIM 7.0:
- EC001261
- ETIM 8.0:
- EC001261
- ETIM 9.0:
- EC001261
- ETIM 10.0:
- EC001261
- Datasheet:
- View
- Declaration of Conformity:
- View
