Harmony XB4

Harmony XB4

  • Schneider Electric XB4AB1 22Mm Pb W/ Contact Block + 6 Colors

    Schneider Electric XB4AB1 22Mm Pb W/ Contact Block + 6 Colors

    Schneider Electric

    $26.30
    This push-button provides an ergonomic interface for controlling your machines Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations It is impact resistant, dust...
    SKU:
    XB4AB1
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
    Sustainable Offer Status:
    Green Premium product
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Operating Force:
    3.8 N NO changing electrical state
    Mechanical Durability:
    5000000 cycles
    Contacts Material:
    silver alloy (Ag/Ni)
    Overvoltage Category:
    class I IEC 60536
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Range Of Product:
    Harmony XB4
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Ambient Air Temperature For Operation:
    -25-70 °C
    Net Weight:
    0.08 kg
    Type Of Operator:
    spring return
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Positive Opening:
    without
    Device Presentation:
    complete product
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Circularity Profile:
    ENVEOLI1808008EN
    Standards:
    IEC 60947-1 || IEC 60947-5-5 || UL 508 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-5-1 || JIS C8201-1
    Fixing Collar Material:
    zamak
    Operating Travel:
    2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Product Or Component Type:
    push-button
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Bezel Material:
    chromium plated metal
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Product Certifications:
    CSA || LROS (Lloyds register of shipping) || BV || UL Listed || GL || DNV
    Depth:
    52 mm
    Contact Operation:
    slow-break
    Environmental Disclosure:
    ENVPEP1808008EN
    Device Short Name:
    XB4
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Protective Treatment:
    TH
    Ambient Air Temperature For Storage:
    -40-70 °C
    Rohs Exemption Information:
    Yes
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Mounting Diameter:
    22 mm
    Mercury Free:
    Yes
    Width:
    30 mm
    China Rohs Regulation:
    X
    Sale Per Indivisible Quantity:
    1
    Contacts Type And Composition:
    1 NO
    Ik Degree Of Protection:
    IK03 IEC 50102
    Terminals Description Iso N°1:
    (13-14)NO
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Height:
    47 mm
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Operator Profile:
    6 colors choice flush, unmarked
    Ip Degree Of Protection:
    IP66 IEC 60529
    Shape Of Signaling Unit Head:
    round
    Contacts Usage:
    standard contacts
    $26.30
  • Schneider Electric XB4AS1 22Mm 2 Pos Sel Sw

    Schneider Electric XB4AS1 22Mm 2 Pos Sel Sw

    Schneider Electric

    $38.30
    This push-button provides an ergonomic interface for controlling your machines Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations It is impact resistant, dust...
    SKU:
    XB4AS1
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Ambient Air Temperature For Operation:
    -25-70 °C
    China Rohs Regulation:
    X
    Contact Operation:
    slow-break
    Contacts Type And Composition:
    1 NO
    Positive Opening:
    without
    Terminals Description Iso N°1:
    (3-4)NO
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Contacts Usage:
    standard contacts
    Standards:
    IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || IEC 60947-1 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-5-5 || JIS C8201-1
    Rohs Exemption Information:
    Yes
    Depth:
    68 mm
    Operator Profile:
    black standard handle
    Sustainable Offer Status:
    Green Premium product
    Product Certifications:
    BV || UL || CSA || DNV || LROS (Lloyds register of shipping) || GL
    Width:
    30 mm
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Torque Value:
    0.14 N.m NO changing electrical state
    Protective Treatment:
    TH
    Device Short Name:
    XB4
    Sale Per Indivisible Quantity:
    1
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Device Presentation:
    complete product
    Mounting Diameter:
    22 mm
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Product Or Component Type:
    selector switch
    Operator Position Information:
    2 positions 90°
    Range Of Product:
    Harmony XB4
    Net Weight:
    0.095 kg
    Type Of Operator:
    stay put
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Shape Of Signaling Unit Head:
    round
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Mercury Free:
    Yes
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Circularity Profile:
    ENVEOLI1808008EN
    Ip Degree Of Protection:
    IP69K IEC 60529
    Mechanical Durability:
    1000000 cycles
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN 60947-5-1 appendix C || 1000000 cycles, DC-13, 0.2
    Overvoltage Category:
    class I IEC 60536
    Ambient Air Temperature For Storage:
    -40-70 °C
    Bezel Material:
    chromium plated metal
    Contacts Material:
    silver alloy (Ag/Ni)
    Fixing Collar Material:
    zamak
    Height:
    47 mm
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Environmental Disclosure:
    ENVPEP1808008EN
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end IEC 60947-1
    $38.30
  • Schneider Electric ZBY8630 E. Stop Legend Plate Pack of 10

    Schneider Electric ZBY8630 E. Stop Legend Plate Pack of 10

    Schneider Electric

    $61.20
    This Harmony ZBY circular legend for emergency stop function has yellow background and is marked with "ARRESTO DE EMERGENZA" lettering, and a diameter of 90mm. It is compatible with Harmony XB4, XB5 and XB7 push buttons and pilot lights. This circular...
    SKU:
    ZBY8630
    Environmental Disclosure:
    ENVPEP1710010EN
    China Rohs Regulation:
    X
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Label Dimensions:
    Ø 90 mm
    Mercury Free:
    Yes
    Material:
    plastic
    Accessory / Separate Part Type:
    legend
    Sustainable Offer Status:
    Green Premium product
    Rohs Exemption Information:
    Yes
    Standards:
    EN/IEC 60204-1 || EN/ISO 13850: 2006
    Range Of Product:
    Harmony XB4 || Harmony XB5
    Sale Per Indivisible Quantity:
    1
    Circularity Profile:
    ENVEOLI1710010EN
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Marking:
    black ARRESTO EMERGENZA yellow
    Accessory / Separate Part Category:
    marking accessories
    User Language:
    Italian
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Net Weight:
    0.008 kg
    Toxic Heavy Metal Free:
    Yes
    Warranty:
    18 months
    Product Or Component Type:
    marked legend
    Reach Free Of Svhc:
    Yes
    Brochure:
    View
    Datasheet:
    View
    $61.20
  • Schneider Electric XB4BW3545 Illuminated Pushbutton

    Schneider Electric XB4BW3545 Illuminated Pushbutton

    Schneider Electric

    $244.50
    This Harmony XB4 plain lens illuminated modular orange push button operates with a spring return / impulse mechanism, is supplied with 220V to 240V AC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button...
    SKU:
    XB4BW3545
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Height:
    47 mm
    Light Source:
    incandescent
    Circularity Profile:
    ENVEOLI1808008EN
    Ambient Air Temperature For Storage:
    -40-70 °C
    Ambient Air Temperature For Operation:
    -40-55 °C
    Contacts Type And Composition:
    1 NO + 1 NC
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Operator Additional Information:
    with plain lens
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Bulb Base:
    BA 9s
    Net Weight:
    0.17 kg
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Protective Treatment:
    TH
    Bezel Material:
    chromium plated metal
    Terminals Description Iso N°1:
    (13-14)NO || (21-22)NC
    [Us] Rated Supply Voltage:
    220...240 V AC 50/60 Hz
    Device Presentation:
    complete product
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    Positive Opening:
    with IEC 60947-5-1 appendix K
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Device Short Name:
    XB4
    Depth:
    101 mm
    Warranty:
    18 months
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Contact Operation:
    slow-break
    Fixing Collar Material:
    zamak
    Rohs Exemption Information:
    Yes
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Ik Degree Of Protection:
    IK06 IEC 50102
    China Rohs Regulation:
    X
    Product Or Component Type:
    illuminated push-button
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Environmental Disclosure:
    ENVPEP1808008EN
    Mercury Free:
    Yes
    Signalling Type:
    steady
    Contacts Material:
    silver alloy (Ag/Ni)
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Mounting Diameter:
    22 mm
    Sale Per Indivisible Quantity:
    1
    Contacts Usage:
    standard contacts
    Electrical Shock Protection Class:
    class I IEC 60536
    Width:
    30 mm
    Head Type:
    standard
    Standards:
    IEC 60947-5-5 || CSA C22.2 No 14 || IEC 60947-1 || UL 508 || IEC 60947-5-4 || JIS C8201-5-1 || IEC 60947-5-1 || JIS C8201-1
    Operator Profile:
    orange flush
    Type Of Operator:
    spring return
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Sustainable Offer Status:
    Green Premium product
    Product Certifications:
    DNV || CSA || UL Listed || BV || GL || LROS (Lloyds register of shipping)
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Range Of Product:
    Harmony XB4
    Mechanical Durability:
    10000000 cycles
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Shape Of Signaling Unit Head:
    round
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    $244.50
  • Schneider Electric XB4BW3345 Illuminated Pushbutton

    Schneider Electric XB4BW3345 Illuminated Pushbutton

    Schneider Electric

    $163.00
    This Harmony XB4 plain lens illuminated modular green push button operates with a spring return / impulse mechanism, is supplied with 220V to 240V AC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button with...
    SKU:
    XB4BW3345
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Net Weight:
    0.17 kg
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Contacts Type And Composition:
    1 NO + 1 NC
    Contact Operation:
    slow-break
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    Sustainable Offer Status:
    Green Premium product
    Type Of Operator:
    spring return
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Protective Treatment:
    TH
    Operator Additional Information:
    with plain lens
    Standards:
    IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || IEC 60947-1 || UL 508 || JIS C8201-5-1 || IEC 60947-5-5 || JIS C8201-1
    Product Certifications:
    UL Listed || DNV || LROS (Lloyds register of shipping) || BV || GL || CSA
    Ik Degree Of Protection:
    IK06 IEC 50102
    Ambient Air Temperature For Storage:
    -40-70 °C
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Mercury Free:
    Yes
    China Rohs Regulation:
    X
    Terminals Description Iso N°1:
    (21-22)NC || (13-14)NO
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Range Of Product:
    Harmony XB4
    Electrical Shock Protection Class:
    class I IEC 60536
    Circularity Profile:
    ENVEOLI1808008EN
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Product Or Component Type:
    illuminated push-button
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Width:
    30 mm
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Rohs Exemption Information:
    Yes
    Fixing Collar Material:
    zamak
    Signalling Type:
    steady
    Sale Per Indivisible Quantity:
    1
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    [Us] Rated Supply Voltage:
    220...240 V AC 50/60 Hz
    Contacts Usage:
    standard contacts
    Warranty:
    18 months
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Light Source:
    incandescent
    Bezel Material:
    chromium plated metal
    Head Type:
    standard
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Mounting Diameter:
    22 mm
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Bulb Base:
    BA 9s
    Height:
    47 mm
    Positive Opening:
    with IEC 60947-5-1 appendix K
    Ambient Air Temperature For Operation:
    -40-55 °C
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Device Short Name:
    XB4
    Depth:
    101 mm
    Mechanical Durability:
    10000000 cycles
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Environmental Disclosure:
    ENVPEP1808008EN
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Shape Of Signaling Unit Head:
    round
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Contacts Material:
    silver alloy (Ag/Ni)
    Device Presentation:
    complete product
    Operator Profile:
    green flush
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $163.00
  • Schneider Electric XB4BW3445 Illuminated Pushbutton

    Schneider Electric XB4BW3445 Illuminated Pushbutton

    Schneider Electric

    $244.50
    This Harmony XB4 plain lens illuminated modular red push button operates with a spring return / impulse mechanism, is supplied with 220V to 240V AC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button with...
    SKU:
    XB4BW3445
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Operator Profile:
    red flush
    Range Of Product:
    Harmony XB4
    Sustainable Offer Status:
    Green Premium product
    Ambient Air Temperature For Operation:
    -40-55 °C
    Contacts Type And Composition:
    1 NO + 1 NC
    Bezel Material:
    chromium plated metal
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Height:
    47 mm
    Mounting Diameter:
    22 mm
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Width:
    30 mm
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Bulb Base:
    BA 9s
    Positive Opening:
    with IEC 60947-5-1 appendix K
    Light Source:
    incandescent
    Mercury Free:
    Yes
    Environmental Disclosure:
    ENVPEP1808008EN
    Terminals Description Iso N°1:
    (13-14)NO || (21-22)NC
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Warranty:
    18 months
    Contacts Material:
    silver alloy (Ag/Ni)
    Product Or Component Type:
    illuminated push-button
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Mechanical Durability:
    10000000 cycles
    Sale Per Indivisible Quantity:
    1
    Depth:
    101 mm
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Fixing Collar Material:
    zamak
    Type Of Operator:
    spring return
    Electrical Shock Protection Class:
    class I IEC 60536
    Contact Operation:
    slow-break
    Operator Additional Information:
    with plain lens
    Signalling Type:
    steady
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    China Rohs Regulation:
    X
    Net Weight:
    0.17 kg
    Circularity Profile:
    ENVEOLI1808008EN
    Device Presentation:
    complete product
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Product Certifications:
    GL || CSA || DNV || UL Listed || LROS (Lloyds register of shipping) || BV
    Device Short Name:
    XB4
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Protective Treatment:
    TH
    Rohs Exemption Information:
    Yes
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Ambient Air Temperature For Storage:
    -40-70 °C
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    Contacts Usage:
    standard contacts
    Standards:
    IEC 60947-1 || JIS C8201-5-1 || UL 508 || IEC 60947-5-5 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-1
    Shape Of Signaling Unit Head:
    round
    [Us] Rated Supply Voltage:
    220...240 V AC 50/60 Hz
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Head Type:
    standard
    Ik Degree Of Protection:
    IK06 IEC 50102
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $244.50
  • Schneider Electric XB4BW3335 Illuminated Pushbutton

    Schneider Electric XB4BW3335 Illuminated Pushbutton

    Schneider Electric

    $163.00
    This Harmony XB4 plain lens illuminated modular green push button operates with a spring return / impulse mechanism, is supplied with 110V to 120V AC/DC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button...
    SKU:
    XB4BW3335
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Positive Opening:
    with IEC 60947-5-1 appendix K
    Sustainable Offer Status:
    Green Premium product
    Ambient Air Temperature For Storage:
    -40-70 °C
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    China Rohs Regulation:
    X
    Contact Operation:
    slow-break
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Operator Profile:
    green flush
    Product Certifications:
    GL || BV || CSA || UL Listed || DNV || LROS (Lloyds register of shipping)
    Width:
    30 mm
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Type Of Operator:
    spring return
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Bulb Base:
    BA 9s
    Device Presentation:
    complete product
    Net Weight:
    0.169 kg
    Shape Of Signaling Unit Head:
    round
    Product Or Component Type:
    illuminated push-button
    Operator Additional Information:
    with plain lens
    Contacts Material:
    silver alloy (Ag/Ni)
    Mounting Diameter:
    22 mm
    Depth:
    101 mm
    Mercury Free:
    Yes
    Terminals Description Iso N°1:
    (13-14)NO || (21-22)NC
    Rohs Exemption Information:
    Yes
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Light Source:
    incandescent
    Head Type:
    standard
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Environmental Disclosure:
    ENVPEP1808008EN
    Warranty:
    18 months
    Signalling Type:
    steady
    Electrical Shock Protection Class:
    class I IEC 60536
    Device Short Name:
    XB4
    Range Of Product:
    Harmony XB4
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Mechanical Durability:
    10000000 cycles
    Sale Per Indivisible Quantity:
    1
    Fixing Collar Material:
    zamak
    Ambient Air Temperature For Operation:
    -40-55 °C
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Height:
    47 mm
    Protective Treatment:
    TH
    Contacts Usage:
    standard contacts
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Circularity Profile:
    ENVEOLI1808008EN
    Ik Degree Of Protection:
    IK06 IEC 50102
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    Standards:
    IEC 60947-5-1 || IEC 60947-1 || IEC 60947-5-4 || CSA C22.2 No 14 || JIS C8201-5-1 || IEC 60947-5-5 || UL 508 || JIS C8201-1
    Bezel Material:
    chromium plated metal
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    [Us] Rated Supply Voltage:
    110...120 V AC 50/60 Hz
    Contacts Type And Composition:
    1 NO + 1 NC
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $163.00
  • Schneider Electric XB4BW3135 Illuminated Pushbutton

    Schneider Electric XB4BW3135 Illuminated Pushbutton

    Schneider Electric

    $244.50
    This Harmony XB4 plain lens illuminated modular white push button operates with a spring return / impulse mechanism, is supplied with 110V to 120V AC/DC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button...
    SKU:
    XB4BW3135
    Contacts Type And Composition:
    1 NO + 1 NC
    Terminals Description Iso N°1:
    (21-22)NC || (13-14)NO
    Product Or Component Type:
    illuminated push-button
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Product Certifications:
    GL || CSA || LROS (Lloyds register of shipping) || DNV || UL Listed || BV
    Net Weight:
    0.169 kg
    Bulb Base:
    BA 9s
    Ambient Air Temperature For Operation:
    -40-55 °C
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Environmental Disclosure:
    ENVPEP1808008EN
    Ambient Air Temperature For Storage:
    -40-70 °C
    Circularity Profile:
    ENVEOLI1808008EN
    Ik Degree Of Protection:
    IK06 IEC 50102
    [Us] Rated Supply Voltage:
    110...120 V AC 50/60 Hz
    Range Of Product:
    Harmony XB4
    Type Of Operator:
    spring return
    Light Source:
    incandescent
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Device Presentation:
    complete product
    Mercury Free:
    Yes
    Signalling Type:
    steady
    Warranty:
    18 months
    China Rohs Regulation:
    X
    Protective Treatment:
    TH
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Mounting Diameter:
    22 mm
    Shape Of Signaling Unit Head:
    round
    Sale Per Indivisible Quantity:
    1
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Head Type:
    standard
    Operator Additional Information:
    with plain lens
    Rohs Exemption Information:
    Yes
    Contacts Material:
    silver alloy (Ag/Ni)
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Height:
    47 mm
    Sustainable Offer Status:
    Green Premium product
    Device Short Name:
    XB4
    Bezel Material:
    chromium plated metal
    Operator Profile:
    white flush
    Mechanical Durability:
    10000000 cycles
    Contact Operation:
    slow-break
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Electrical Shock Protection Class:
    class I IEC 60536
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Depth:
    101 mm
    Width:
    30 mm
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Fixing Collar Material:
    zamak
    Positive Opening:
    with IEC 60947-5-1 appendix K
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Standards:
    UL 508 || IEC 60947-1 || JIS C8201-5-1 || IEC 60947-5-4 || IEC 60947-5-1 || CSA C22.2 No 14 || IEC 60947-5-5 || JIS C8201-1
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Contacts Usage:
    standard contacts
    $244.50
  • Schneider Electric XB4BW3435 Illuminated Pushbutton

    Schneider Electric XB4BW3435 Illuminated Pushbutton

    Schneider Electric

    $244.50
    This Harmony XB4 plain lens illuminated modular red push button operates with a spring return / impulse mechanism, is supplied with 110V to 120V AC/DC, uses an integral transformer with Integral LED. It has a metal bezel. This illuminated push button...
    SKU:
    XB4BW3435
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Ik Degree Of Protection:
    IK06 IEC 50102
    Rohs Exemption Information:
    Yes
    Contacts Type And Composition:
    1 NO + 1 NC
    Tightening Torque:
    0.8-1.2 N.m IEC 60947-1
    Range Of Product:
    Harmony XB4
    Head Type:
    standard
    Type Of Operator:
    spring return
    Sale Per Indivisible Quantity:
    1
    Depth:
    101 mm
    China Rohs Regulation:
    X
    Mechanical Durability:
    10000000 cycles
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Operator Profile:
    red flush
    Light Source:
    incandescent
    Operating Travel:
    1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
    Fixing Collar Material:
    zamak
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Electrical Durability:
    1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Device Presentation:
    complete product
    Ambient Air Temperature For Operation:
    -40-55 °C
    Contacts Usage:
    standard contacts
    Electrical Reliability:
    λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
    Shape Of Signaling Unit Head:
    round
    Net Weight:
    0.169 kg
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Operator Additional Information:
    with plain lens
    Height:
    47 mm
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    [Us] Rated Supply Voltage:
    110...120 V AC 50/60 Hz
    Short-Circuit Protection:
    10 A cartridge fuse gG IEC 60947-5-1
    Standards:
    CSA C22.2 No 14 || JIS C8201-5-1 || IEC 60947-5-1 || IEC 60947-5-4 || IEC 60947-5-5 || IEC 60947-1 || UL 508 || JIS C8201-1
    Electrical Shock Protection Class:
    class I IEC 60536
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    [Ith] Conventional Free Air Thermal Current:
    10 A IEC 60947-5-1
    Mounting Diameter:
    22 mm
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Product Certifications:
    UL Listed || CSA || DNV || LROS (Lloyds register of shipping) || BV || GL
    Protective Treatment:
    TH
    Shape Of Screw Head:
    cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
    Bezel Material:
    chromium plated metal
    Device Short Name:
    XB4
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Warranty:
    18 months
    Product Or Component Type:
    illuminated push-button
    Operating Force:
    3.5 N NC changing electrical state || 3.8 N
    Terminals Description Iso N°1:
    (13-14)NO || (21-22)NC
    Mercury Free:
    Yes
    [Ie] Rated Operational Current:
    3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
    Sustainable Offer Status:
    Green Premium product
    Contact Operation:
    slow-break
    Positive Opening:
    with IEC 60947-5-1 appendix K
    Bulb Base:
    BA 9s
    Ambient Air Temperature For Storage:
    -40-70 °C
    Width:
    30 mm
    Contacts Material:
    silver alloy (Ag/Ni)
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    Circularity Profile:
    ENVEOLI1808008EN
    Environmental Disclosure:
    ENVPEP1808008EN
    Signalling Type:
    steady
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $244.50
  • Schneider Electric XB4BV35 Transformer 120 V Pilot L

    Schneider Electric XB4BV35 Transformer 120 V Pilot L

    Schneider Electric

    $128.70
    This Harmony XB4 plain lens modular orange pilot light is supplied with 110V to 120V AC/DC, uses BA9s base. It has a metal bezel. This pilot light, designed to last without maintenance for a bright indicator of process and machine operations, is easily...
    SKU:
    XB4BV35
    Device Short Name:
    XB4
    Light Block Supply:
    via integral transformer 1.2 VA 6 V
    Device Presentation:
    complete product
    Electrical Shock Protection Class:
    class I IEC 60536
    Standards:
    IEC 60947-5-5 || UL 508 || JIS C8201-5-1 || IEC 60947-5-4 || IEC 60947-5-1 || IEC 60947-1 || CSA C22.2 No 14 || JIS C8201-1
    Signalling Type:
    steady
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Bezel Material:
    chromium plated metal
    Ambient Air Temperature For Storage:
    -40-70 °C
    Mercury Free:
    Yes
    Shape Of Signaling Unit Head:
    round
    Warranty:
    18 months
    Circularity Profile:
    ENVEOLI2308026EN
    Sustainable Offer Status:
    Green Premium product
    Mounting Diameter:
    22 mm
    Weee:
    The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Sale Per Indivisible Quantity:
    1
    Product Or Component Type:
    pilot light
    Net Weight:
    0.152 kg
    Range Of Product:
    Harmony XB4
    Width:
    30 mm
    Vibration Resistance:
    5 gn 12-500 Hz)IEC 60068-2-6
    Fixing Collar Material:
    zamak
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Light Source:
    incandescent
    Head Type:
    standard
    [Us] Rated Supply Voltage:
    110...120 V AC 50/60 Hz
    Ik Degree Of Protection:
    IK06 IEC 50102
    Depth:
    78 mm
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    China Rohs Regulation:
    X
    [Uimp] Rated Impulse Withstand Voltage:
    6 kV IEC 60947-1
    Connections - Terminals:
    screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
    Environmental Disclosure:
    ENVPEP2308026EN
    Product Certifications:
    UL Listed || CSA
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Bulb Base:
    BA 9s
    Terminals Description Iso N°1:
    (X1-X2)PL
    Ambient Air Temperature For Operation:
    -40-55 °C
    Height:
    47 mm
    Operator Additional Information:
    with plain lens
    Resistance To High Pressure Washer:
    7000000 Pa 55 °C 0.1 m
    [Ui] Rated Insulation Voltage:
    600 V 3)IEC 60947-1
    Rohs Exemption Information:
    Yes
    Protective Treatment:
    TH
    Cap/Operator Or Lens Colour:
    orange
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $128.70
  • Schneider Electric ZBA639 Cap R Pack of 10

    Schneider Electric ZBA639 Cap R Pack of 10

    Schneider Electric

    $42.00
    This Harmony ZB, flush blue marked push button cap has a round shape with "R" symbol. This push button cap provides an ergonomic interface for controlling your machine thanks to its flush element. It is supplied ready engraved with a marking relevant to...
    SKU:
    ZBA639
    Rohs Exemption Information:
    Yes
    Marking:
    white R
    Warranty:
    18 months
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Accessory / Separate Part Destination:
    push-button head
    User Language:
    International
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Range Compatibility:
    Harmony XB4 || Harmony XB5 || Harmony XAL
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Accessory / Separate Part Type:
    marked push-button cap
    Sustainable Offer Status:
    Green Premium product
    China Rohs Regulation:
    X
    Main Group:
    push-button
    Operator Profile:
    flush
    Mercury Free:
    Yes
    Accessory / Separate Part Category:
    marking accessory
    Circularity Profile:
    ENVEOLI1808008EN
    Cap/Operator Or Lens Colour:
    blue
    Net Weight:
    0.001 kg
    Reach Free Of Svhc:
    Yes
    Toxic Heavy Metal Free:
    Yes
    Shape Of Signaling Unit Head:
    round
    Sale Per Indivisible Quantity:
    10
    Environmental Disclosure:
    ENVPEP1808008EN
    Quantity Per Set:
    set of 1
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $42.00
  • Schneider Electric ZBW911 Ill. P.B. Light Lens Pack of 10

    Schneider Electric ZBW911 Ill. P.B. Light Lens Pack of 10

    Schneider Electric

    $81.00
    This Harmony ZB, white lens cap has a round shape. It is compatible with Harmony XB4 and XB5 push button with flush push and BA9s base. This lens cap provides clear visual feedback on the status of your machines. It is easily installed and replaced on...
    SKU:
    ZBW911
    Cap/Operator Or Lens Colour:
    white
    Product Compatibility:
    BA 9s
    Accessory / Separate Part Type:
    cap
    Marking:
    unmarked
    Mercury Free:
    Yes
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Environmental Disclosure:
    ENVPEP1808008EN
    Accessory / Separate Part Category:
    lighting accessories
    Shape Of Signaling Unit Head:
    round
    Accessory / Separate Part Designation:
    lens cap
    Sustainable Offer Status:
    Green Premium product
    Circularity Profile:
    ENVEOLI1808008EN
    Warranty:
    18 months
    Toxic Heavy Metal Free:
    Yes
    China Rohs Regulation:
    X
    Net Weight:
    0.002 kg
    Accessory / Separate Part Destination:
    illuminated push-button with flush push
    Cap Or Lens Type:
    plain lens
    Rohs Exemption Information:
    Yes
    Reach Free Of Svhc:
    Yes
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Quantity Per Set:
    set of 10
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Range Of Product:
    Harmony XB4 || Harmony XB5
    Brochure:
    View
    Datasheet:
    View
    $81.00
  • Schneider Electric ZBA435 Cap Off Pack of 10

    Schneider Electric ZBA435 Cap Off Pack of 10

    Schneider Electric

    $63.00
    This Harmony ZB, flush red marked push button cap has a round shape with "OFF" symbol. This push button cap provides an ergonomic interface for controlling your machine thanks to its flush element. It is supplied ready engraved with a marking relevant to...
    SKU:
    ZBA435
    Accessory / Separate Part Category:
    marking accessory
    Environmental Disclosure:
    ENVPEP1808008EN
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Shape Of Signaling Unit Head:
    round
    Net Weight:
    0.001 kg
    Quantity Per Set:
    set of 1
    Sale Per Indivisible Quantity:
    10
    Mercury Free:
    Yes
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Circularity Profile:
    ENVEOLI1808008EN
    Operator Profile:
    flush
    User Language:
    English
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    China Rohs Regulation:
    X
    Accessory / Separate Part Type:
    marked push-button cap
    Sustainable Offer Status:
    Green Premium product
    Rohs Exemption Information:
    Yes
    Range Compatibility:
    Harmony XB4 || Harmony XB5 || Harmony XAL
    Marking:
    white OFF
    Cap/Operator Or Lens Colour:
    red
    Reach Free Of Svhc:
    Yes
    Toxic Heavy Metal Free:
    Yes
    Warranty:
    18 months
    Accessory / Separate Part Destination:
    push-button head
    Main Group:
    push-button
    Datasheet:
    View
    $63.00
  • Schneider Electric ZBL1 Cap For Extended Push But Pack of 10

    Schneider Electric ZBL1 Cap For Extended Push But Pack of 10

    Schneider Electric

    $30.00
    This Harmony ZB, projecting white unmarked push button cap has a round shape. It is compatible with Harmony XB4 and XB5 push buttons. This push button cap provides an ergonomic interface for controlling your machine. It is supplied without marking in...
    SKU:
    ZBL1
    Sale Per Indivisible Quantity:
    10
    Main Group:
    push-button
    Shape Of Signaling Unit Head:
    round
    Net Weight:
    0.001 kg
    Operator Profile:
    projecting
    Accessory / Separate Part Type:
    blank push-button cap
    Cap/Operator Or Lens Colour:
    white
    Accessory / Separate Part Category:
    marking accessory
    Warranty:
    18 months
    Accessory / Separate Part Destination:
    push-button head
    Circularity Profile:
    ENVEOLI1808008EN
    Mercury Free:
    Yes
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Rohs Exemption Information:
    Yes
    China Rohs Regulation:
    X
    Environmental Disclosure:
    ENVPEP1808008EN
    Quantity Per Set:
    set of 1
    Toxic Heavy Metal Free:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Range Compatibility:
    Harmony XB4 || Harmony XAL || Harmony XB5
    Reach Free Of Svhc:
    Yes
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Brochure:
    View
    Datasheet:
    View
    $30.00
  • Schneider Electric ZBL4 Cap For Extended Push But Pack of 10

    Schneider Electric ZBL4 Cap For Extended Push But Pack of 10

    Schneider Electric

    $30.00
    This Harmony ZB, projecting red unmarked push button cap has a round shape. It is compatible with Harmony XB4 and XB5 push buttons. This push button cap provides an ergonomic interface for controlling your machine. It is supplied without marking in order...
    SKU:
    ZBL4
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Quantity Per Set:
    set of 1
    Shape Of Signaling Unit Head:
    round
    Reach Free Of Svhc:
    Yes
    Circularity Profile:
    ENVEOLI1808008EN
    Cap/Operator Or Lens Colour:
    red
    Accessory / Separate Part Destination:
    push-button head
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Warranty:
    18 months
    Accessory / Separate Part Category:
    marking accessory
    Environmental Disclosure:
    ENVPEP1808008EN
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Sustainable Offer Status:
    Green Premium product
    Accessory / Separate Part Type:
    blank push-button cap
    China Rohs Regulation:
    X
    Rohs Exemption Information:
    Yes
    Main Group:
    push-button
    Mercury Free:
    Yes
    Range Compatibility:
    Harmony XB4 || Harmony XAL || Harmony XB5
    Toxic Heavy Metal Free:
    Yes
    Operator Profile:
    projecting
    Sale Per Indivisible Quantity:
    10
    Net Weight:
    0.001 kg
    Brochure:
    View
    Datasheet:
    View
    $30.00
  • Schneider Electric ZBV014 Pilot Light Lens Pack of 10

    Schneider Electric ZBV014 Pilot Light Lens Pack of 10

    Schneider Electric

    $54.00
    This Harmony ZB, red lens cap has a round shape. It is compatible with Harmony XB4 and XB5 pilot lights with BA9s base. This lens cap provides clear visual feedback on the status of your machines. It is easily installed and replaced on compatible pilot...
    SKU:
    ZBV014
    Accessory / Separate Part Type:
    cap
    Reach Regulation:
    Reference contains Substances of Very High Concern above the threshold
    Marking:
    unmarked
    Warranty:
    18 months
    Net Weight:
    0.002 kg
    Shape Of Signaling Unit Head:
    round
    Ambient Air Temperature For Operation:
    -40-70 °C
    Product Compatibility:
    BA 9s
    Range Of Product:
    Harmony XB5 || Harmony XB4
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Quantity Per Set:
    set of 10
    Mercury Free:
    Yes
    Product Or Component Type:
    plain lens
    Rohs Exemption Information:
    Yes
    Cap/Operator Or Lens Colour:
    red
    Circularity Profile:
    ENVEOLI1808008EN
    China Rohs Regulation:
    X
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Cap Or Lens Type:
    plain lens
    Sustainable Offer Status:
    Green Premium product
    Accessory / Separate Part Destination:
    pilot light
    Accessory / Separate Part Category:
    lighting accessories
    Accessory / Separate Part Designation:
    lens cap
    Environmental Disclosure:
    ENVPEP1808008EN
    Brochure:
    View
    Datasheet:
    View
    $54.00
  • Schneider Electric ZBW915 Ill. P.B. Light Lens Pack of 10

    Schneider Electric ZBW915 Ill. P.B. Light Lens Pack of 10

    Schneider Electric

    $81.00
    This Harmony ZB, orange lens cap has a round shape. It is compatible with Harmony XB4 and XB5 push button with flush push and BA9s base. This lens cap provides clear visual feedback on the status of your machines. It is easily installed and replaced on...
    SKU:
    ZBW915
    Mercury Free:
    Yes
    Accessory / Separate Part Destination:
    illuminated push-button with flush push
    Environmental Disclosure:
    ENVPEP1808008EN
    Cap Or Lens Type:
    plain lens
    China Rohs Regulation:
    X
    Warranty:
    18 months
    Quantity Per Set:
    set of 10
    Product Compatibility:
    BA 9s
    Accessory / Separate Part Category:
    lighting accessories
    Cap/Operator Or Lens Colour:
    orange
    Accessory / Separate Part Designation:
    lens cap
    Accessory / Separate Part Type:
    cap
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Sustainable Offer Status:
    Green Premium product
    Circularity Profile:
    ENVEOLI1808008EN
    Range Of Product:
    Harmony XB5 || Harmony XB4
    Marking:
    unmarked
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Toxic Heavy Metal Free:
    Yes
    Rohs Exemption Information:
    Yes
    Net Weight:
    0.002 kg
    Shape Of Signaling Unit Head:
    round
    Reach Free Of Svhc:
    Yes
    Brochure:
    View
    Catalog:
    View
    Datasheet:
    View
    $81.00
  • Schneider Electric ZB4BS62 Emergency Stop Op. Head

    Schneider Electric ZB4BS62 Emergency Stop Op. Head

    Schneider Electric

    $135.00
    This Harmony XB4, 60mm mushroom black button head operates with latched turn to release mechanism. This 60mm mushroom shaped push button head is ideal for situations where quick actions are required for a process or machine to function correctly or where...
    SKU:
    ZB4BS62
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Cad Overall Depth:
    57 mm
    Reach Free Of Svhc:
    Yes
    Toxic Heavy Metal Free:
    Yes
    Operator Profile:
    black mushroom Ø 60 mm, unmarked
    Device Presentation:
    basic element
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Ik Degree Of Protection:
    IK03 IEC 50102
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Rohs Exemption Information:
    Yes
    Mechanical Durability:
    500000 cycles
    Circularity Profile:
    ENVEOLI2201004EN
    Overvoltage Category:
    class I IEC 60536
    China Rohs Regulation:
    X
    Type Of Operator:
    latching
    Cad Overall Width:
    60 mm
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Reset:
    turn to release
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Bezel Material:
    chromium plated metal
    Mounting Diameter:
    22 mm
    Protective Treatment:
    TH
    Range Of Product:
    Harmony XB4
    Product Certifications:
    LROS (Lloyds register of shipping) || DNV || GL || CSA || UL Listed || BV
    Warranty:
    18 months
    Product Or Component Type:
    head for non-illuminated push-button
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Mercury Free:
    Yes
    Cad Overall Height:
    60 mm
    Environmental Disclosure:
    ENVPEP2201004EN
    Ambient Air Temperature For Storage:
    -40-70 °C
    Standards:
    EN/IEC 60947-5-4 || UL 508 || EN/IEC 60947-5-5 || EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
    Shape Of Signaling Unit Head:
    round
    Sale Per Indivisible Quantity:
    1
    Net Weight:
    0.09 kg
    Ambient Air Temperature For Operation:
    -40-70 °C
    Electrical Composition Code:
    C11 3 single front mounting || C15 1 single front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C10 4 single and double front mounting
    Sustainable Offer Status:
    Green Premium product
    Head Type:
    standard
    Device Short Name:
    ZB4
    $135.00
  • Schneider Electric ZB4BZ079 Xb4B Pcb Bracket

    Schneider Electric ZB4BZ079 Xb4B Pcb Bracket

    Schneider Electric

    $3.40
    This Harmony XB4, body/fixing collar allows to connect together XB4 heads with printed circuit board. It is made of metal and is compatible with Harmony XB4. It has a metal bezel, this makes it Ideal for severe environments, especially applications...
    SKU:
    ZB4BZ079
    Accessory / Separate Part Type:
    body fixing collar
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Net Weight:
    0.003 kg
    Warranty:
    18 months
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Circularity Profile:
    ENVEOLI1808008EN
    Toxic Heavy Metal Free:
    Yes
    Additional Information:
    must be used in conjunction with adaptor ZBZ010
    Reach Free Of Svhc:
    Yes
    Accessory / Separate Part Category:
    mounting and fixing accessories
    Mercury Free:
    Yes
    Sustainable Offer Status:
    Green Premium product
    Accessory / Separate Part Destination:
    printed circuit board support
    China Rohs Regulation:
    X
    Accessory / Separate Part Designation:
    fixing collar
    Environmental Disclosure:
    ENVPEP1808008EN
    Rohs Exemption Information:
    Yes
    Product Or Component Type:
    body fixing collar
    Material:
    metal
    Quantity Per Set:
    set of 10
    Range Of Product:
    Harmony XB4
    Catalog:
    View
    Datasheet:
    View
    $3.40
  • Schneider Electric ZB4BR316 Mushroomm Push But Head

    Schneider Electric ZB4BR316 Mushroomm Push But Head

    Schneider Electric

    $75.00
    This Harmony XB4, 60mm mushroom green button head operates with a spring return / impulse mechanism. This 60mm mushroom shaped push button head is ideal for situations where quick actions are required for a process or machine to function correctly or...
    SKU:
    ZB4BR316
    Operator Profile:
    green mushroom Ø 60 mm, unmarked
    Mounting Diameter:
    22 mm
    Rohs Exemption Information:
    Yes
    Toxic Heavy Metal Free:
    Yes
    Ambient Air Temperature For Storage:
    -40-70 °C
    Mechanical Durability:
    5000000 cycles
    Bezel Material:
    chromium plated metal
    Range Of Product:
    Harmony XB4
    Type Of Operator:
    spring return
    Ip Degree Of Protection:
    IP66 IEC 60529 || IP67 || IP69 || IP69K
    Standards:
    CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || EN/IEC 60947-5-5 || JIS C8201-5-1 || UL 508 || JIS C8201-1
    Ik Degree Of Protection:
    IK03 IEC 50102
    China Rohs Regulation:
    X
    Reach Free Of Svhc:
    Yes
    Device Short Name:
    ZB4
    California Proposition 65:
    WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    Eu Rohs Directive:
    Pro-active compliance (Product out of EU RoHS legal scope)
    Nema Degree Of Protection:
    NEMA 13 || NEMA 4X
    Shape Of Signaling Unit Head:
    hemispherical
    Vibration Resistance:
    5 gn 2-500 Hz)IEC 60068-2-6
    Sustainable Offer Status:
    Green Premium product
    Environmental Disclosure:
    ENVPEP1808008EN
    Head Type:
    standard
    Warranty:
    18 months
    Product Or Component Type:
    head for non-illuminated push-button
    Product Certifications:
    GL || BV || CSA || LROS (Lloyds register of shipping) || UL Listed || DNV
    Sale Per Indivisible Quantity:
    1
    Cad Overall Depth:
    45 mm
    Reach Regulation:
    Free of Substances of Very High Concern above the threshold
    Protective Treatment:
    TH
    Cad Overall Width:
    60 mm
    Device Presentation:
    basic element
    Overvoltage Category:
    class I IEC 60536
    Ambient Air Temperature For Operation:
    -40-70 °C
    Mercury Free:
    Yes
    Electrical Composition Code:
    C11 3 single front mounting || C15 1 single front mounting || C3 6 single front mounting || C4 6 single and double front mounting
    Cad Overall Height:
    60 mm
    Shock Resistance:
    30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    Circularity Profile:
    ENVEOLI1808008EN
    Catalog:
    View
    Datasheet:
    View
    $75.00
