Leuze BT 346M.5-180 Mounting device
Leuze
$38.00
The Leuze BT 346M.5-180 is a mounting device designed specifically for the (M)TKS 40x60 reflector, featuring a mounting plate configuration with through-hole mounting for secure and precise installation. It enables reliable positioning of 40x60 mm reflectors in photoelectric sensor applications, supporting robust mechanical fixation in industrial environments. Ideal for manufacturing setups requiring stable reflector alignment for detection tasks.
Documentation
- Technical Datasheet: https://www.leuze.com/en-int/bt-346m.5-180/50148134
- Product Downloads: https://www.leuze.com/en-int/downloads?product=BT-346M.5-180
- CAD Data: https://www.leuze.com/en-int/cad-data?part=50148134
- Installation Guide: https://www.leuze.com/en-int/installation?product=BT-346M.5-180
- Suitable for product group:
- Reflectors
- Suitable for:
- Reflector (M)TKS 40x60
- Standard designation, metal mounting device:
- Steel, galvanized
- Design of mounting device:
- Mounting plate
- Type of fastening, at system:
- Through-hole mounting
- Type of fastening, at device:
- Screw type
- Type of mounting device:
- Rigid
- Mounting device material:
- Metal
- Customs tariff number:
- 73181900
- ECLASS 5.1.4:
- 27279202
- ECLASS 8.0:
- 27279202
- ECLASS 9.0:
- 27273701
- ECLASS 10.0:
- 27273701
- ECLASS 11.0:
- 27273701
- ECLASS 12.0:
- 27273701
- ECLASS 13.0:
- 27273701
- ECLASS 14.0:
- 27273701
- ECLASS 15.0:
- 27273701
- ETIM 5.0:
- EC002498
- ETIM 6.0:
- EC003015
- ETIM 7.0:
- EC003015
- ETIM 8.0:
- EC003015
- ETIM 9.0:
- EC003015
- ETIM 10.0:
- EC003015
- Datasheet:
- View
