Leuze AC-ALM Industrial Sensor System
Leuze
$394.00
The AC-ALM is a precision industrial sensor engineered for demanding automation applications. Featuring IP-rated protection and wide operating temperature range, it delivers reliable performance in manufacturing, logistics, and process control environments.
Technical Documentation:
Complete technical specifications, dimensional drawings, wiring diagrams, and safety documentation are available on the Leuze website at https://www.leuze.com/en-us/usa/products (search model AC-ALM). CAD models in STEP and EPLAN formats available for download to streamline machine design and panel layout.
- Suitable for:
- MLC 500, MLC 300 safety light curtains
- Receiver operating range:
- 30 m
- Voltage supply:
- 2 AA batteries, replaceable, 2x1.5V
- Operational readiness:
- Approx. 8 hours in continuous operation at average intensity
- Dimension (W x H x L):
- 53 mm x 76 mm x 32.5 mm
- Housing material:
- Plastic
- Plastic housing:
- ABS
- Housing color:
- Black
- Type of display:
- 5 multi-color LEDs
- Operational controls:
- Control buttons
- US patents:
- US 9,503,184 B
- Customs tariff number:
- 85389099
- ECLASS 5.1.4:
- 27279210
- ECLASS 8.0:
- 27279210
- ECLASS 9.0:
- 27273607
- ECLASS 10.0:
- 27273607
- ECLASS 11.0:
- 27273607
- ECLASS 12.0:
- 27273607
- ECLASS 13.0:
- 27273607
- ECLASS 14.0:
- 27273607
- ECLASS 15.0:
- 27273607
- ETIM 5.0:
- EC002498
- ETIM 6.0:
- EC003015
- ETIM 7.0:
- EC003015
- ETIM 8.0:
- EC003015
- ETIM 9.0:
- EC003015
- ETIM 10.0:
- EC003015
- Datasheet:
- View
- Declaration of Conformity:
- View
