KDS PB-M12-4A-M12-8A-P0-020 Interconnection cable

Leuze KDS PB-M12-4A-M12-8A-P0-020 Interconnection cable

Leuze
SKU:
KDS PB-M12-4A-M12-8A-P0-020
Availability:
Contact us to confirm availability and lead times.
$138.76
Condition:
New
Current Stock:
Description

KDS PB-M12-4A-M12-8A-P0-020 Interconnection cable

Additional Information
Application:
Oil and lubricant resistant
Suitable for interface:
PROFIBUS DP
Operating voltage:
Max. 30 V AC/DC
Type:
Male
No. of pins:
8 -pin
Encoding:
A-coded
Connector, LED:
No
Type:
Female
No. of pins:
4 -pin
Encoding:
B-coded
Sheathing color:
Gray
Shielded:
Yes
Silicone-free:
Yes
Cable design:
Interconnection cable
Cable length:
2,000 mm
Sheathing material:
PUR
Wire insulation:
PP
Suitability for drag chains:
Yes
Properties of the outer sheathing:
Free of CFC, cadmium, silicone, halogen and lead, matt, low-adhesion, abrasion-resistant, easily machine-processable
Resistance of the outer sheathing:
Hydrolysis and microbe resistant, good oil, gasoline and chemical resistance in accordance with VDE 0472 part 803 test B, flame retardant in accordance with UL 1581 VW1 / CSA FT1 / IEC 60332-1, IEC 60332-2-2
Width across flats:
13 mm
Bending cycles:
5,000,000 Piece(s)
Bending radius, flexible laying, min.:
Min. 12 x cable diameter
Bending radius, stationary laying, min.:
Min. 7.5 x cable diameter
Degree of protection:
IP 65,IP 66K,IP 67
Customs tariff number:
85444290
ECLASS 5.1.4:
27279201
ECLASS 8.0:
27279218
ECLASS 9.0:
27060311
ECLASS 10.0:
27060311
ECLASS 11.0:
27060311
ECLASS 12.0:
27060311
ECLASS 13.0:
27060311
ECLASS 14.0:
27060311
ECLASS 15.0:
27060311
ETIM 5.0:
EC001855
ETIM 6.0:
EC001855
ETIM 7.0:
EC001855
ETIM 8.0:
EC001855
ETIM 9.0:
EC001855
ETIM 10.0:
EC001855
Datasheet:
View
Brochure:
View
