Leuze PRK46C.1/6G-M12 Polarized retro-reflective photoelectric sensor
Leuze
$200.31
(No reviews yet)
Write a Review
Write a Review
Leuze
Leuze PRK46C.1/6G-M12 Polarized retro-reflective photoelectric sensor
Polarized retro-reflective photoelectric sensor
- Series:
- 46C
- Operating principle:
- Reflection principle
- Operating range:
- 0.1 ... 24 m, With reflector TK(S) 100x100
- Operating range:
- Guaranteed operating range
- Operating range limit:
- 0.1 ... 30 m, With reflector TK(S) 100x100
- Operating range limit:
- Typical operating range
- Light source:
- LED, Red
- Wavelength:
- 630 nm
- LED group:
- Exempt group (in acc. with EN 62471)
- Protective circuit:
- Polarity reversal protection,Short circuit protected,Transient protection
- Supply voltage UB:
- 10 ... 30 V, DC, Incl. residual ripple
- Residual ripple:
- 0 ... 15 %, From UB
- Open-circuit current:
- 0 ... 20 mA
- Number of digital switching outputs:
- 2 Piece(s)
- Switching principle:
- Light switching (PNP)/dark switching (NPN)
- Switching principle:
- Dark switching (PNP)/light switching (NPN)
- Switching frequency:
- 500 Hz
- Response time:
- 1 ms
- Readiness delay:
- 300 ms
- Function:
- Signal OUT,Voltage supply
- Type of connection:
- Connector
- Thread size:
- M12
- Type:
- Male
- Material:
- Plastic
- No. of pins:
- 4 -pin
- Encoding:
- A-coded
- Dimension (W x H x L):
- 20.5 mm x 76.3 mm x 44 mm
- Housing material:
- Plastic
- Plastic housing:
- PC-PBT
- Lens cover material:
- Plastic / PMMA
- Net weight:
- 60 g
- Housing color:
- Red
- Type of fastening:
- Through-hole mounting,Via optional mounting device
- Compatibility of materials:
- ECOLAB
- Type of display:
- LED
- Operational controls:
- 270° potentiometer
- Ambient temperature, operation:
- -40 ... 60 °C
- Ambient temperature, storage:
- -40 ... 70 °C
- Degree of protection:
- IP 67,IP 69K
- Protection class:
- III
- Approvals:
- c UL US
- Standards applied:
- IEC 60947-5-2
- Customs tariff number:
- 85365019
- ECLASS 5.1.4:
- 27270902
- ECLASS 8.0:
- 27270902
- ECLASS 9.0:
- 27270902
- ECLASS 10.0:
- 27270902
- ECLASS 11.0:
- 27270902
- ECLASS 12.0:
- 27270902
- ECLASS 13.0:
- 27270902
- ECLASS 14.0:
- 27270902
- ECLASS 15.0:
- 27270902
- ETIM 5.0:
- EC002717
- ETIM 6.0:
- EC002717
- ETIM 7.0:
- EC002717
- ETIM 8.0:
- EC002717
- ETIM 9.0:
- EC002717
- ETIM 10.0:
- EC002717
- Datasheet:
- View
- Brochure:
- View
- Declaration of Conformity:
- View
