Leuze LS49CI.UC Throughbeam photoelectric sensor transmitter
Leuze
$210.56
(No reviews yet)
Write a Review
Write a Review
Leuze
Leuze LS49CI.UC Throughbeam photoelectric sensor transmitter
LS49CI.UC Throughbeam photoelectric sensor transmitter
- Series:
- 49C
- Operating principle:
- Throughbeam principle
- Device type:
- Transmitter
- Operating range:
- 0.5 ... 120 m
- Operating range:
- Guaranteed operating range
- Operating range limit:
- 0 ... 150 m
- Operating range limit:
- Typical operating range
- Light source:
- LED, Infrared
- Wavelength:
- 860 nm
- LED group:
- Exempt group (in acc. with EN 62471)
- Protective circuit:
- Polarity reversal protection,Short circuit protected,Transient protection
- Supply voltage UB:
- 20 ... 250 V, AC/DC
- Power consumption (with AC):
- 1.5 V·A
- Readiness delay:
- 300 ms
- Function:
- Voltage supply
- Type of connection:
- Cable
- Cable length:
- 2,000 mm
- Sheathing material:
- PVC
- Cable color:
- Black
- Number of conductors:
- 2 -wire
- Wire cross section:
- 0.34 mm²
- Dimension (W x H x L):
- 31 mm x 104 mm x 55.5 mm
- Housing material:
- Plastic
- Plastic housing:
- PC
- Lens cover material:
- Plastic
- Net weight:
- 150 g
- Housing color:
- Red
- Type of fastening:
- Through-hole mounting,Via optional mounting device
- Type of display:
- LED
- Ambient temperature, operation:
- -40 ... 60 °C
- Ambient temperature, storage:
- -40 ... 70 °C
- Degree of protection:
- IP 67
- Protection class:
- II
- Approvals:
- c UL US
- Standards applied:
- IEC 60947-5-2
- Customs tariff number:
- 85365080
- ECLASS 5.1.4:
- 27270901
- ECLASS 8.0:
- 27270901
- ECLASS 9.0:
- 27270901
- ECLASS 10.0:
- 27270901
- ECLASS 11.0:
- 27270901
- ECLASS 12.0:
- 27270901
- ECLASS 13.0:
- 27270901
- ECLASS 14.0:
- 27270901
- ECLASS 15.0:
- 27270901
- ETIM 5.0:
- EC002716
- ETIM 6.0:
- EC002716
- ETIM 7.0:
- EC002716
- ETIM 8.0:
- EC002716
- ETIM 9.0:
- EC002716
- ETIM 10.0:
- EC002716
- Datasheet:
- View
- Brochure:
- View
- Declaration of Conformity:
- View
