Lutze LSC051102B2R5 lsc

Lutze LSC051102B2R5 lsc

Lutze
SKU:
LSC051102B2R5
Availability:
Contact us to confirm availability and lead times.
$438.81
Condition:
New
Current Stock:
Description

Technical Data

Input

Input signal
4????20 mA
Input variable
Single analogue signal
Galvanic isolation I/O
2-way isolation
Input overload capability
max. 35 mA

Output

Output signal
4????20 mA
Max. load impedance at I-output
1000 ? (RB)
Residual ripple
<5 mVeff (load impedance 100 ?)

Operating data

Accuracy
0.1 % FSR @ 23 ???C
Build-up time (Accuracy 1%)
6 ms (for working resistance 500 ? and 20 mA)

General

Rated voltage UN
passive
Status indication
LED green
Input/output protection
Suppressor diode (33 V)
Burden error
<0.06 % from measured value / 100 ? working resistance
Temperature drift /K
<150 ppm / K FSR
Temperature drift (working resistance >600R)
<100 ppm / K FSR
Temperature drift (working resistance >600R)
<150 ppm / K FSR
Insulation voltage input / output
1.5 kVeff
Housing material
PA 6.6 (UL 94 V-0, NFF I2, F2)
Color of the housing
  • RAL 7012
  • basalt grey
Mounting
  • DIN rail mountable TS35
  • (EN 60715)
Protection class
IP20
Installation position
any
Connection type
  • Screwed terminal
  • single wire
  • 0.25 mm2????2.5 mm2 / AWG 20????14
  • fine stranded wire with ferrule
  • 0.25 mm2????1.5 mm2 / AWG 20????16
Operation temperature range
-25 ???C ???? +60 ???C
Storage temperature range
-40???C????80???C
Dimensions (w ????? h ????? d)
6,2?????93?????71 mm
Weight
0,04 kg/piece
PU
1 piece
Approvals
  • cULus (E135145)
  • DNV GL
Standards
EN 60947-5-1
Comments
With connection: This passive isolator has a non-reactive transmission, so that the current in the input circuit is not interrupted for an output interruption.
Dimensions
PIN assignment
Action chart
