Nexen 801539 Torque Limiter Coupling Adapter
NexenTorque Limiter Coupling Adapter
TL50*ADAPTER RING,COUPLING
Shaft to Shaft, Misalignment Capability
Application Considerations: Coupling Bolts To The Clutch Pilot To Allow Shaft To Shaft Coupling Adapter Allows The Use Of Standard Gear Coupling Half Coupling Half's Not Provided By Nexen, May Be Available From Dodge, Falk, Koppers, Philadelphia, Zurn, And Possibly Others For Greater Misalignment Capability See Nexen's Single And Double Flex Couplings Nexen Does Not Provide The Taper Lock Bushing
Bore Size=Up To 2.188 in, Varies With Coupling Half Supplier; Max Angular MisAlignment=0.75 °
Product Features=Shaft to Shaft, Misalignment Capability
- Weight:
- 9 lbs
- Primary Finish:
- Black Oxide
- CE Certified:
- CE
- RoHS Compliant:
- RoHS
- Bore Details:
- Taper Lock Per Supplier
- Materials Of Construction:
- Black Oxide
- QN-QUOTE-REQUEST:
- true
