Description
Robotiq's Camera brings Plug + Play vision for Universal Robots. (Cables sold separately.)
- 5-minute setup time
- Perfect fit for all UR wrists
- Software embedded on UR’s user interface, Polyscope
- Simple object teaching interface
- Autonomous location of objects on work surface
- No custom wiring required
- No coding required
- No external PC required to set up, program or run Camera
This camera is designed specifically for Universal Robots industrial robot arms. Cables sold separately.
Robotiq Wrist Camera Specsheet
| Metric | Imperial | |
| MAXIMAL RESOLUTION | 5 Mpx @ 2fps (2560 X 1920) | 5 Mpx @ 2fps (2560 X 1920) |
| MAXIMAL FRAMERATE | 30 fps @ 0.3 Mpx (640 X 480) | 30 fps @ 0.3 Mpx (640 X 480) |
| ACTIVE ARRAY SIZE | 2592 X 1944 | 2592 X 1944 |
| FOCUS RANGE | 70 mm to infinity | 2.76 in to infinity |
| ADDED HEIGHT | 13.5 mm (Without tool plate) and 23.5 mm (With tool plate) | 0.53 in (Without tool plate) and 0.93 in (With tool plate) |
| COMPATIBILITY: UNIVERSAL ROBOTS UR3, UR5 & UR10 WITH CONTROLLER CB3.1 OR HIGHER ONLY |
Camera only. Complete camera install kit available here. Robot arms sold separately.
