Schneider Electric 8501RSD34V53 Relay 240Vac 5Amp Type R +Options

(No reviews yet) Write a Review
SKU:
8501RSD34V53
UPC:
785901031895
Condition:
New
Warranty:
18 months
Maximum Switching Voltage:
30 V DC || 240 V AC
China Rohs Regulation:
X
Shape Of Pin:
spade
Product Compatibility:
8501NR45
Switch Function:
4PDT
Environmental Disclosure:
ENVPEP1511008EN
Reach Free Of Svhc:
Yes
Rated Power In Hp:
not rated
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Operating Time:
20 ms - pick-up || 20 ms - drop-out
Mercury Free:
Yes
Rated Breaking Capacity:
5 A 120 V AC resistive control circuit UL 508 || 5 A 240 V AC resistive control circuit UL 508 || 5 A 30 V DC resistive control circuit UL 508
Relay Type:
low voltage
Toxic Heavy Metal Free:
Yes
Local Signalling:
no indicator
Range Of Product:
8501R
Product Certifications:
UL Listed || UL Recognized || CSA || CE
Depth:
38.9 mm
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Ambient Air Temperature For Operation:
-40-131 °F
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Circularity Profile:
N/A
Contacts Material:
hermetically sealed silver tin oxide
[Uc] Control Circuit Voltage:
24 V DC
Height:
29.4 mm
Product Or Component Type:
Miniature Relay
Rohs Exemption Information:
Yes
Width:
23.1 mm
Control Type:
without test button
Mounting Support:
socket
Sustainable Offer Status:
Green Premium product
Catalog:
View
Datasheet:
View
  • Schneider Electric 8501RSD34V53 Relay 240Vac 5Amp Type R +Options
  • Schneider Electric 8501RSD34V53 Relay 240Vac 5Amp Type R +Options
  • Schneider Electric 8501RSD34V53 Relay 240Vac 5Amp Type R +Options
$64.66

Description

8501RS miniature plug in relays are designed for use in Class 1 Division 2 hazardous locations. These relays are designed to be plugged into a relay socket. This makes for very easy replacement. This relay plugs into an 8501NR45 or 8501NR45B relay socket. Relay is available with 4PDT contact arrangements. It has four normally open and four normally closed contacts. The contacts have a 5 ampere resistive rating at 240 VAC, at 120 VAC and at 30 VDC. Relays can be ordered with a wide variety of coil voltages. This relay has a 24 VDC nonreplaceable coil. Relay does not have a green LED indicator. 8501RS relays are UL listed with Square D relay sockets, UL component recognized and CSA certified.
