Schneider Electric 8501XO40V03 Relay 600Vac 10Amp Nema +Options
NEMA Control Relay, Type X, machine tool, 10A resistive at 600 VAC, 4 normally open contacts, 220/240 VAC 50/60 Hz coil
- Width:
- 2.23 in
- Relay Type:
- control
- [Icm] Rated Short-Circuit Making Capacity:
- 60 A 120 V AC inductive control circuit UL 508 || 0.8 A 250 V DC resistive control circuit UL 508 || 30 A 240 V AC inductive control circuit UL 508 || 15 A 480 V AC inductive control circuit UL 508 || 12 A 600 V AC inductive control circuit UL 508 ||
- Ambient Air Temperature For Operation:
- -40-160 °F
- Control Circuit Voltage Limits:
- operational 0.85...1.1 Uc AC 50/60 Hz
- Circularity Profile:
- ENVEOLI1310013
- Range Of Product:
- 8501X
- Contacts Type And Composition:
- 4 NO 4 standard contact cartridges
- [Uc] Control Circuit Voltage:
- 220 V AC 50 Hz || 240 V AC 60 Hz
- Mounting Support:
- panel
- Line Rated Current:
- 10 A AC || 5 A DC
- Depth:
- 3.95 in
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Mercury Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Electrical Connection:
- screw clamp terminals
- Awg Gauge:
- AWG 18...AWG 12 copper
- China Rohs Regulation:
- X
- Product Or Component Type:
- relay
- Rohs Exemption Information:
- Yes
- Inrush Power In Va:
- 148-148 VA 60 Hz || 143-143 VA 50 Hz
- Operating Time:
- 15 ms - pick-up || 16 ms - drop-out
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Height:
- 3.5 in
- Environmental Disclosure:
- ENVPEP1310013EN
- Hold-In Power Consumption In Va:
- 23-23 VA 60 Hz || 25-25 VA 50 Hz
- Rated Breaking Capacity:
- 6 A 120 V AC inductive control circuit UL 508 || 0.8 A 250 V DC resistive control circuit UL 508 || 3 A 240 V AC inductive control circuit UL 508 || 1.5 A 480 V AC inductive control circuit UL 508 || 1.2 A 600 V AC inductive control circuit UL 508 ||
- Product Certifications:
- UL listed file E78403 CCN NKCR || CSA LR60905 class 3211 03
- Warranty:
- 18 months
- Tightening Torque:
- control circuit 1.02-1.36 N.m screw terminals
