Schneider Electric 8910DP41V14 Contactor 600Vac 40Amp Dp +Options

Schneider Electric 8910DP41V14 Contactor 600Vac 40Amp Dp +Options

Schneider Electric
SKU:
8910DP41V14
|
UPC:
785901233053
Availability:
Contact us to confirm availability and lead times.
$69.50
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
8910DP definite purpose magnetic contactors are designed for heating, air conditioning and refrigeration applications. This line of definite purpose contactors has current ratings up to 120 amperes resistive and 50 HP at 600 VAC. This one pole definite purpose contactor has a full load rating of 40 ampere and a resistive rating of 50 amperes at 277 V maximum. The nonreplaceable coil is available with a variety of coil voltages. This device has a 24 VAC 50/60 Hz coil. The contactor has straight through wiring. Contactor is 2.00 inches by 3.29 inches and 2.39 tall. These contactors are UL Listed and CSA Certified.
Additional Information
Product Or Component Type:
Definite Purpose Contactor
Electrical Connection:
quick connect terminals || box lugs
Warranty:
18 months
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Pole Contact Composition:
1 NO
[Ue] Rated Operational Voltage:
600 V AC
Locked Rotor Rated Current:
240 A 277 V AC || 200 A 460 V AC || 160 A 575 V AC
Eu Rohs Directive:
Compliant with Exemptions
Rohs Exemption Information:
Yes
Line Rated Current:
40 A
Poles Description:
1P
Maximum Horse Power Rating:
2-2 hp 115 V AC, 1 phase || 5-5 hp 230 V AC, 1 phase
Phase:
1 phase
[Uc] Control Circuit Voltage:
24 V AC 50/60 Hz
Product Certifications:
UL Recognized || CSA
Mercury Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Range Of Product:
DP
Catalog:
View
Datasheet:
View
