Schneider Electric 9001KP1G6 Pilot Light 120Vac 30Mm Type K +Options

(No reviews yet) Write a Review

Write a Review

Schneider Electric 9001KP1G6 Pilot Light 120Vac 30Mm Type K +Options

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

9001KP1G6

UPC:

785901859925

MPN:

Condition:

New

Mounting Diameter:

30 mm

Warranty:

18 months

Device Short Name:

K

Size:

30 mm

Rohs Exemption Information:

Yes

Bulb Base:

BA 9s

Lens Material:

glass

Connections - Terminals:

screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1

Light Source:

incandescent

Shape Of Screw Head:

round

Lens Type:

domed

Circularity Profile:

N/A

Product Certifications:

UL listed file E42259 CCN NKCR || CE || CSA LR25490 class 3211 03

Mercury Free:

Yes

Supply Frequency:

50...60 Hz

Lens Type:

domed glass

[Us] Rated Supply Voltage:

110...120 V AC

Light Source:

incandescent bulb

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Operating Position:

any position

Nema Degree Of Protection:

NEMA 1/2/3/3R/4/6/12/13

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Light Block Supply:

via integral transformer

[Us] Rated Supply Voltage:

110...120 V

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Bezel Material:

metal

Range Of Product:

Harmony 9001K

Device Presentation:

complete product

Environmental Disclosure:

ENVPEP121006EN

Product Or Component Type:

pilot light

China Rohs Regulation:

X

Sustainable Offer Status:

Green Premium product

Operating Mode:

normal

Light Block Supply:

via transformer 120 V AC 50/60 Hz || via integral transformer 110 V AC 50/60 Hz

Cap/Operator Or Lens Colour:

green

Brochure:

View

Datasheet:

View
