Schneider Electric 9001KP1LGG31 Pilot Light 120Vac 30Mm Type K +Options

(No reviews yet) Write a Review

Write a Review

Schneider Electric 9001KP1LGG31 Pilot Light 120Vac 30Mm Type K +Options

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

9001KP1LGG31

UPC:

7.85902E+11

MPN:

Condition:

New

[Us] Rated Supply Voltage:

110...120 V

Light Source:

Green LED

Lens Type:

fresnel

Shape Of Signaling Unit Head:

round

Lens Type:

domed plastic

Ambient Air Temperature For Storage:

-40-70 °C

Supply Frequency:

50...60 Hz

Light Block Supply:

via integral transformer

Product Or Component Type:

pilot light

[Ui] Rated Insulation Voltage:

250 V 2)IEC 60947-1

Light Source Colour:

green

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Cad Overall Depth:

42 mm

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Device Short Name:

9001K

Ambient Air Temperature For Operation:

-25-70 °C

Sustainable Offer Status:

Green Premium product

Shape Of Screw Head:

cross slotted

[Ith] Conventional Free Air Thermal Current:

0.416666666666667

Rohs Exemption Information:

Yes

Standards:

EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || JIS C8201-5-1 || EN/IEC 60947-1 || CSA C22.2 No 14 || UL 508 || JIS C 852 || JIS C8201-1

Protective Treatment:

TC

Connections - Terminals:

screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1

Net Weight:

0.21 kg

Overvoltage Category:

class II IEC 61140

Product Certifications:

NEMA || UL 508

China Rohs Regulation:

X

Environmental Disclosure:

ENVPEP121006EN

Cad Overall Width:

54 mm

Bulb Base:

BA 9s

Circularity Profile:

N/A

Short-Circuit Protection:

10 A cartridge fuse IEC 60947-5-1

Vibration Resistance:

7 gn 2-500 Hz)IEC 60068-2-6

Nema Degree Of Protection:

NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6

Mercury Free:

Yes

Operating Position:

any position

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Size:

30 mm

Shock Resistance:

50 gn IEC 60068-2-27

Ip Degree Of Protection:

IP66 IEC 60529

Range Of Product:

Harmony 9001K

[Uimp] Rated Impulse Withstand Voltage:

2.5 kV IEC 60947-1

Mounting Diameter:

30 mm

Light Block Supply:

direct 110...120 V AC 50/60 Hz

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Tightening Torque:

0.8-0.8 N.m IEC 60947-1

Bezel Material:

metal

Cap/Operator Or Lens Colour:

green

Cad Overall Height:

70 mm

Light Source:

LED

Lens Material:

polycarbonate

Warranty:

18 months
