Schneider Electric 9001KP40R9 Pushbutton Pilot Light30Mm 20-30V Sk
SKU:
9001KP40R9
UPC:
3389119011044
MPN:
Condition:
New
Light Block Supply:
direct 250 V AC/DC
China Rohs Regulation:
X
Light Source:
incandescent
Cad Overall Height:
70 mm
Product Certifications:
NEMA || UL 508
Tightening Torque:
0.8-0.8 N.m IEC 60947-1
Light Block Supply:
full voltage
Ambient Air Temperature For Storage:
-40-70 °C
Ambient Air Temperature For Operation:
-25-70 °C
Overvoltage Category:
class II IEC 61140
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Bulb Base:
BA 9s
Device Short Name:
9001K
Sustainable Offer Status:
Green Premium product
Product Or Component Type:
pilot light
Cap/Operator Or Lens Colour:
red
[Us] Rated Supply Voltage:
6 V
Light Source:
bulb not included
[Ui] Rated Insulation Voltage:
250 V 2)IEC 60947-1
Short-Circuit Protection:
10 A cartridge fuse IEC 60947-5-1
Net Weight:
0.134 kg
Shape Of Screw Head:
cross slotted
Cad Overall Width:
54 mm
Cad Overall Depth:
42 mm
Protective Treatment:
TC
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Ip Degree Of Protection:
IP66 IEC 60529
Shape Of Signaling Unit Head:
round
Environmental Disclosure:
ENVPEP121006EN
Warranty:
18 months
Lens Type:
domed
Mounting Diameter:
30 mm
Vibration Resistance:
7 gn 2-500 Hz)IEC 60068-2-6
[Ith] Conventional Free Air Thermal Current:
0.416666666666667
Nema Degree Of Protection:
NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6
Range Of Product:
Harmony 9001K
Lens Material:
polycarbonate
[Uimp] Rated Impulse Withstand Voltage:
2.5 kV IEC 60947-1
Connections - Terminals:
screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
Standards:
UL 508 || EN/IEC 60947-5-4 || EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C 852 || JIS C8201-1
Size:
30 mm
Lens Type:
fresnel plastic
Mercury Free:
Yes
Circularity Profile:
N/A
Shock Resistance:
50 gn IEC 60068-2-27
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Rohs Exemption Information:
Yes
Operating Position:
any position
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
