Schneider Electric 9001KP7LRR9 30Mm Pilot Light, 220-240V, Red Led
This Harmony 9001K, red pilot light with integral LED and plastic dome is supplied with 240V AC. It has a chromium-plated metal bezel. This single component pilot light provides clear visual feedback on the status of your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.
- Shape Of Signaling Unit Head:
- round
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6
- Standards:
- UL 508 || CSA C22.2 No 14 || JIS C 852 || EN/IEC 60947-5-1 || JIS C8201-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || JIS C8201-1
- Shock Resistance:
- 50 gn IEC 60068-2-27
- Cad Overall Width:
- 54 mm
- Cad Overall Depth:
- 42 mm
- [Us] Rated Supply Voltage:
- 220...240 V
- Light Block Supply:
- via integral transformer
- Device Presentation:
- complete product
- Net Weight:
- 0.21 kg
- Light Source:
- Red LED
- Cap/Operator Or Lens Colour:
- red
- Supply Frequency:
- 50...60 Hz
- Ambient Air Temperature For Operation:
- -25-70 °C
- Circularity Profile:
- N/A
- Ip Degree Of Protection:
- IP66 IEC 60529
- Short-Circuit Protection:
- 10 A cartridge fuse IEC 60947-5-1
- Lens Material:
- polycarbonate
- Bulb Base:
- BA 9s
- Sustainable Offer Status:
- Green Premium product
- Light Block Supply:
- direct 220...240 V AC 50/60 Hz 6 V)
- Shape Of Screw Head:
- cross slotted
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Device Short Name:
- 9001K
- Tightening Torque:
- 0.8-0.8 N.m IEC 60947-1
- Bezel Material:
- metal
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV IEC 60947-1
- Lens Type:
- fresnel plastic
- China Rohs Regulation:
- X
- Mercury Free:
- Yes
- Lens Type:
- domed
- [Ui] Rated Insulation Voltage:
- 250 V 2)IEC 60947-1
- Overvoltage Category:
- class II IEC 61140
- Cad Overall Height:
- 70 mm
- Mounting Diameter:
- 30 mm
- Operating Position:
- any position
- Protective Treatment:
- TC
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- [Us] Rated Supply Voltage:
- 220...240 V AC
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Ambient Air Temperature For Storage:
- -40-70 °C
- Product Certifications:
- UL 508 || NEMA
- Light Source Colour:
- red
- Environmental Disclosure:
- ENVPEP121006EN
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Range Of Product:
- Harmony 9001K
- Size:
- 30 mm
- Warranty:
- 18 months
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Light Source:
- LED
- Product Or Component Type:
- pilot light
