Schneider Electric 9001KR1GH6 Pushbutton 600Vac 10A 30Mm Type K
Schneider Electric
$99.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric 9001KR1GH6 Pushbutton 600Vac 10A 30Mm Type K
This Harmony 9001K, modular flush green push button with full guard has 2 positions, operates with spring return mechanism. It has a chromium-plated metal bezel, has 1 x NC contact and uses screw-clamp terminals. This flush push button with full guard provides an ergonomic interface for controlling your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.
- Mounting Diameter:
- 30 mm
- Operator Profile:
- flush
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Type Of Operator:
- spring return
- Contacts Type And Composition:
- 1 NC
- Circularity Profile:
- N/A
- Operating Position:
- any position
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- [Ie] Rated Operational Current:
- 10 A, AC-15 || 10 A, DC-13
- Device Short Name:
- K
- Rohs Exemption Information:
- Yes
- Cap/Operator Or Lens Colour:
- green
- Warranty:
- 18 months
- Bezel Material:
- metal
- Connections - Terminals:
- screw clamp terminals
- Nema Degree Of Protection:
- NEMA 1/2/3/3R/4/6/12/13
- Light Block Supply:
- without supply
- Product Certifications:
- CSA LR 25490 class 3211 03 || CE || NEMA || UL listed file E42259 CCN NKCR
- China Rohs Regulation:
- X
- Sustainable Offer Status:
- Green Premium product
- Range Of Product:
- Harmony 9001K
- Operator Additional Information:
- metal guard
- Size:
- 30 mm
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free:
- Yes
- Contact Operation:
- standard
- Environmental Disclosure:
- ENVPEP121006EN
- Product Or Component Type:
- push-button
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Device Presentation:
- complete product
- Light Source:
- without
- Operator Profile:
- green flush
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
