Schneider Electric 9001KR9R21H6 Push Button 600Vac 10A 30Mm T-K
This Harmony 9001K, modular red push button has 2 positions and operates with a stay-put mechanism. It has a chromium-plated metal bezel, a round shape and 40mm mushroom head and 1 x NC contact. This 40mm mushroom shaped push button head is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is clearly distinguishable visually at a distance thanks to a prominent mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant metal bezel and body ensures product continues to operate even after severe accidents.
- Ip Degree Of Protection:
- IP66 IEC 60529
- Product Or Component Type:
- push-button
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Operator Profile:
- red mushroom à 57 mm, unmarked
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6
- Head Material:
- plastic
- Rated Breaking Capacity:
- 3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
- Contacts Material:
- silver alloy contacts
- Operator Profile:
- mushroom à 57 mm
- Size:
- 30 mm
- Shock Resistance:
- 50 gn IEC 60068-2-27
- Contact Operation:
- standard
- Product Certifications:
- UL 508 || NEMA
- [Ie] Rated Operational Current:
- 3 A 240 V, AC-15, A600-Q600 NEMA || 0.55 A 125 V, DC-13, A600-Q600 NEMA
- Cap/Operator Or Lens Colour:
- red
- Sustainable Offer Status:
- Green Premium product
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Operating Position:
- any position
- Net Weight:
- 0.141 kg
- Operator Position Information:
- 2 positions
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- China Rohs Regulation:
- X
- Overvoltage Category:
- class II IEC 61140
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Rohs Exemption Information:
- Yes
- Ambient Air Temperature For Operation:
- -25-70 °C
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Tightening Torque:
- 0.8-0.8 N.m EN/IEC 60947-1
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Ambient Air Temperature For Storage:
- -40-70 °C
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV EN/IEC 60947-1
- Mounting Diameter:
- 30 mm
- Short-Circuit Protection:
- 10 A cartridge fuse EN/IEC 60947-5-1
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1
- Environmental Disclosure:
- ENVPEP121006EN
- Device Short Name:
- 9001K
- Bezel Material:
- metal
- Positive Opening:
- with IEC 60947-5-2
- Device Presentation:
- complete product
- Standards:
- EN/IEC 60947-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || JIS C 4520 || JIS C 852 || UL 508 || CSA C22.2 No 14
- Warranty:
- 18 months
- [Ui] Rated Insulation Voltage:
- 250 V 3)EN/IEC 60947-1
- Shape Of Screw Head:
- cross slotted
- [Icm] Rated Short-Circuit Making Capacity:
- 12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
- Shape Of Signaling Unit Head:
- round
- Mercury Free:
- Yes
- Operator Additional Information:
- metal guard
- Range Of Product:
- Harmony 9001K
- Circularity Profile:
- N/A
- Protective Treatment:
- TC
- Contacts Type And Composition:
- 1 NC
- Mechanical Durability:
- 5000000 cycles
