Schneider Electric 9001KY4 30Mm Control Station 4Hole Aluminum
Schneider Electric
$228.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric 9001KY4 30Mm Control Station 4Hole Aluminum
This empty enclosure is a separate component of the range of control and signaling units, Harmony 9001K / 9001SK diameter 30mm. It comprises an aluminium enclosure with 4 vertical opening diameter 30mm. It is supplied with 1 entry tapped for 3/4'' cable gland. It weighs 1.846kg. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.
- China Rohs Regulation:
- X
- Toxic Heavy Metal Free:
- Yes
- Cable Entry:
- 1 entry tapped for 3/4'' cable gland
- Ambient Air Temperature For Operation:
- -25-70 °C
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- empty enclosure
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 3 || NEMA 4 || NEMA 6
- Mercury Free:
- Yes
- Protective Treatment:
- TH
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
- Overvoltage Category:
- II IEC 61140
- Sustainable Offer Status:
- Green Premium product
- Product Destination:
- for à 30 mm control and signalling units
- Material:
- aluminium
- Ambient Air Temperature For Storage:
- -40-70 °C
- Reach Free Of Svhc:
- Yes
- Environmental Disclosure:
- ENVPEP121027EN
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Circularity Profile:
- N/A
- Range Of Product:
- Harmony 9001SK || Harmony 9001K
- Number Of Cut-Out:
- 4 cut-outs
- Device Short Name:
- 9001K
- Net Weight:
- 1.84 kg
- Warranty:
- 18 months
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Catalog:
- View
- Datasheet:
- View
