Schneider Electric 9001KYSS3 30Mm Control Station 3Hole Stainless

Schneider Electric 9001KYSS3 30Mm Control Station 3Hole Stainless

Schneider Electric
SKU:
9001KYSS3
|
UPC:
3389118038783
Availability:
Contact us to confirm availability and lead times.
$372.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This empty enclosure is a separate component of the range of control and signaling units, Harmony 9001K / 9001SK diameter 30mm. It comprises a stainless steel enclosure with 3 vertical openings diameter 30mm. It is supplied with 1 entry tapped for 3/4'' knockout. This robust control station complies with the requirements of NEMA 1/13/3/4/4X ratings. It weighs 1.715kg. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.
Additional Information
Reach Free Of Svhc:
Yes
Toxic Heavy Metal Free:
Yes
Mercury Free:
Yes
Material:
stainless steel
Cable Entry:
1 entry tapped for 3/4'' knockout
Device Short Name:
9001K
Environmental Disclosure:
ENVPEP121029EN
Rohs Exemption Information:
Yes
Warranty:
18 months
China Rohs Regulation:
X
Ambient Air Temperature For Operation:
-25-70 °C
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Number Of Cut-Out:
3 cut-outs
Overvoltage Category:
II IEC 61140
Circularity Profile:
N/A
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Net Weight:
1.715 kg
Product Destination:
for Ø 30 mm control and signalling units
Ambient Air Temperature For Storage:
-40-70 °C
Range Of Product:
Harmony 9001SK || Harmony 9001K
Nema Degree Of Protection:
NEMA 1 || NEMA 12 || NEMA 3 || NEMA 4 || NEMA 4X
Protective Treatment:
TH
Sustainable Offer Status:
Green Premium product
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Product Or Component Type:
empty enclosure
