Schneider Electric 9001SKP1LRR31 Pilot Light 120Vac 30Mm Sk +Options
This illuminated red push-to-test pilot light with integral LED provides an ergonomic and visual interface for your machines It is clearly distinguishable visually at a distance thanks to its illuminated head and clear color It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections Tha package dimensions are 5.08 cm (width) x 32.7 cm (length) x 12.9 cm (height) High performance International standards & certifications (Marine ABS certification, Type 1, 2, 3, 3R, 4, 6, 12 and 13)
- Device Short Name:
- 9001SK
- Cad Overall Width:
- 54 mm
- Bulb Base:
- BA 9s
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Environmental Disclosure:
- ENVPEP1710019EN
- Mounting Diameter:
- 30 mm
- Circularity Profile:
- ENVEOLI1710019EN
- [Ui] Rated Insulation Voltage:
- 250 V 2)EN/IEC 60947-1
- Light Source:
- LED
- Lens Material:
- polycarbonate
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Rohs Exemption Information:
- Yes
- [Us] Rated Supply Voltage:
- 110...120 V AC 50/60 Hz
- Ip Degree Of Protection:
- IP66 IEC 60529
- Supply Frequency:
- 50...60 Hz
- Tightening Torque:
- 0.8-0.8 N.m EN/IEC 60947-1
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
- Light Block Supply:
- direct 110...120 V AC 50/60 Hz
- Cad Overall Height:
- 70 mm
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Light Source:
- Red LED
- Cap/Operator Or Lens Colour:
- red
- Mercury Free:
- Yes
- Electrical Shock Protection Class:
- class II IEC 61140
- Product Or Component Type:
- pilot light
- Ambient Air Temperature For Operation:
- -25-70 °C
- Shock Resistance:
- 50 gn IEC 60068-2-27
- Warranty:
- 18 months
- Size:
- 30 mm
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Lens Type:
- fresnel
- Cad Overall Depth:
- 42 mm
- Operating Position:
- any position
- Toxic Heavy Metal Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Light Block Supply:
- via integral transformer
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV EN/IEC 60947-1
- Protective Treatment:
- TC
- Lens Type:
- fresnel plastic
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation:
- X
- Range Of Product:
- Harmony 9001SK
- Light Source Colour:
- red
- Standards:
- CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C 852 || JIS C8201-5-1 || UL 508 || EN/IEC 60947-5-4 || JIS C8201-1
- Net Weight:
- 0.181 kg
- Reach Free Of Svhc:
- Yes
- Shape Of Signaling Unit Head:
- round
- Shape Of Screw Head:
- cross slotted
- [Us] Rated Supply Voltage:
- 110...120 V
- Short-Circuit Protection:
- 10 A cartridge fuse EN/IEC 60947-5-1
- Ambient Air Temperature For Storage:
- -40-70 °C
- Bezel Material:
- plastic
- Product Certifications:
- UL 508 || NEMA
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
