Schneider Electric 9001SKP35LY Pilot Light 28V 30Mm Sk +Options
Schneider Electric
$143.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric 9001SKP35LY Pilot Light 28V 30Mm Sk +Options
Pilot light head, Harmony 9001SK, plastic, without cap, 30mm, LED yellow, 24-28V
- Rohs Exemption Information:
- Yes
- Bezel Material:
- plastic
- Ambient Air Temperature For Operation:
- -25-70 °C
- Light Source Colour:
- yellow
- Cad Overall Height:
- 70 mm
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Light Source:
- LED
- Shape Of Signaling Unit Head:
- round
- Mercury Free:
- Yes
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Light Block Supply:
- direct 24...28 V AC/DC
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
- Tightening Torque:
- 0.8-0.8 N.m IEC 60947-1
- Operating Position:
- any position
- Protective Treatment:
- TC
- Ambient Air Temperature For Storage:
- -40-70 °C
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
- Cad Overall Width:
- 54 mm
- [Us] Rated Supply Voltage:
- 24...28 V AC/DC
- Cap/Operator Or Lens Colour:
- without cap
- Sustainable Offer Status:
- Green Premium product
- Mounting Diameter:
- 30 mm
- Light Source:
- Yellow LED
- Ip Degree Of Protection:
- IP66 IEC 60529
- Standards:
- UL 508 || IEC 60947-1 || JIS C 852 || JIS C8201-5-1 || IEC 60947-5-4 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Range Of Product:
- Harmony 9001SK
- Environmental Disclosure:
- ENVPEP1710019EN
- Product Certifications:
- NEMA || UL 508
- Shape Of Screw Head:
- cross slotted
- [Us] Rated Supply Voltage:
- 24...28 V
- Device Short Name:
- 9001SK
- Product Or Component Type:
- head for pilot light
- [Ui] Rated Insulation Voltage:
- 250 V 2)IEC 60947-1
- Electrical Shock Protection Class:
- class II IEC 61140
- China Rohs Regulation:
- X
- Warranty:
- 18 months
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Toxic Heavy Metal Free:
- Yes
- Bulb Base:
- BA 9s
- Net Weight:
- 0.181 kg
- Size:
- 30 mm
- Circularity Profile:
- ENVEOLI1710019EN
- Short-Circuit Protection:
- 10 A cartridge fuse IEC 60947-5-1
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV IEC 60947-1
- Shock Resistance:
- 50 gn IEC 60068-2-27
- Cad Overall Depth:
- 42 mm
- Reach Free Of Svhc:
- Yes
- Brochure:
- View
- Datasheet:
- View
