Schneider Electric 9001SKP7W31 Pilot Light 240Vac 30Mm Sk +Options
This Harmony 9001SK, white pilot light with transformer and plastic fresnel is supplied with 240V AC. It has a double insulated plastic bezel. It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections. It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant plastic body ensures product continues to operate even after severe accidents.
- Device Presentation:
- complete product
- Range Of Product:
- Harmony 9001SK
- Ambient Air Temperature For Operation:
- -25-70 °C
- Operating Position:
- any position
- [Ith] Conventional Free Air Thermal Current:
- 0.416666666666667
- [Uimp] Rated Impulse Withstand Voltage:
- 2.5 kV EN/IEC 60947-1
- Lens Material:
- polycarbonate
- Net Weight:
- 0.181 kg
- Environmental Disclosure:
- ENVPEP1710019EN
- Standards:
- JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || UL 508 || JIS C 852 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || JIS C8201-1
- Lens Type:
- fresnel plastic
- Size:
- 30 mm
- Tightening Torque:
- 0.8-0.8 N.m EN/IEC 60947-1
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Sustainable Offer Status:
- Green Premium product
- Ambient Air Temperature For Storage:
- -40-70 °C
- Shock Resistance:
- 50 gn IEC 60068-2-27
- Bulb Base:
- BA 9s
- [Us] Rated Supply Voltage:
- 220...240 V AC 50/60 Hz
- Light Source:
- incandescent
- Ip Degree Of Protection:
- IP66 IEC 60529
- Device Short Name:
- 9001SK
- Shape Of Screw Head:
- cross slotted
- Short-Circuit Protection:
- 10 A cartridge fuse EN/IEC 60947-5-1
- Electrical Shock Protection Class:
- class II IEC 61140
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Product Certifications:
- UL 508 || NEMA
- Cad Overall Width:
- 54 mm
- Product Or Component Type:
- pilot light
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Light Block Supply:
- via integral transformer
- Light Source:
- incandescent bulb
- Supply Frequency:
- 50...60 Hz
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
- [Ui] Rated Insulation Voltage:
- 250 V 2)EN/IEC 60947-1
- Toxic Heavy Metal Free:
- Yes
- Connections - Terminals:
- screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1
- Circularity Profile:
- ENVEOLI1710019EN
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Mounting Diameter:
- 30 mm
- [Us] Rated Supply Voltage:
- 220...240 V
- Bezel Material:
- plastic
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Shape Of Signaling Unit Head:
- round
- China Rohs Regulation:
- X
- Warranty:
- 18 months
- Protective Treatment:
- TC
- Lens Type:
- fresnel
- Light Block Supply:
- via integral transformer 220...240 V AC 50/60 Hz 6 V)
- Cad Overall Depth:
- 42 mm
- Rohs Exemption Information:
- Yes
- Reach Free Of Svhc:
- Yes
- Cad Overall Height:
- 70 mm
- Mercury Free:
- Yes
- Cap/Operator Or Lens Colour:
- white
