Schneider Electric 9001SKR24R 30Mm Mushroom Operator Red
Schneider Electric
$81.00
This Harmony 9001SK, modular red push button has 2 positions, operates with spring return mechanism. It has a double insulated plastic bezel, has a round shape with 35mm mushroom head. This 35mm mushroom shaped push button head is ideal for situations where quick actions are required for a process or machine to function correctly or where operator movements require maximum ergonomy. It is easily combined with Harmony range of contact blocks to perform a large variety of control functions. It is clearly distinguishable visually at a distance thanks to a prominent mushroom shape. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant plastic body ensures product continues to operate even after severe accidents.
- Sustainable Offer Status:
- Green Premium product
- Product Certifications:
- CSA LR24590 class 3211 03 || UL listed file E42259 CCN NKCR || CE
- Product Or Component Type:
- head for push-button
- Reach Free Of Svhc:
- Yes
- Cap/Operator Or Lens Colour:
- red
- Size:
- 30 mm
- Operator Profile:
- mushroom à 35 mm
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Toxic Heavy Metal Free:
- Yes
- Type Of Operator:
- spring return
- Ambient Air Temperature For Operation:
- -25-70 °C
- Device Short Name:
- 9001SK
- Overvoltage Category:
- class II IEC 61140
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Mercury Free:
- Yes
- Ip Degree Of Protection:
- IP66
- Circularity Profile:
- N/A
- Vibration Resistance:
- 7 gn 2-500 Hz)IEC 60068-2-6
- Operator Additional Information:
- screw-on plastic with set screw
- Range Of Product:
- Harmony 9001SK
- Bezel Material:
- plastic
- Shape Of Signaling Unit Head:
- round
- Contacts Type And Composition:
- without contact block
- Ambient Air Temperature For Storage:
- -40-70 °C
- China Rohs Regulation:
- X
- Environmental Disclosure:
- EnvPEP120817EN
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Warranty:
- 18 months
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Mechanical Durability:
- 5000000 cycles
- Device Presentation:
- basic element
- Protective Treatment:
- TC
- Nema Degree Of Protection:
- NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
