Schneider Electric 9001SKR4RH5 Pushbutton 600Vac 10Amp 30Mm Sk +Options

Schneider Electric 9001SKR4RH5 Pushbutton 600Vac 10Amp 30Mm Sk +Options

Schneider Electric
SKU:
9001SKR4RH5
|
UPC:
785901183365
$168.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
This Harmony 9001SK, modular flush red push button has 2 positions, operates with spring return mechanism. It has a double insulated plastic bezel, has 1 x NO contact and uses screw-clamp terminals. This flush push button provides an ergonomic interface for controlling your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant plastic body ensures product continues to operate even after severe accidents.
Additional Information
Mounting Diameter:
30 mm
Mechanical Durability:
5000000 cycles
Circularity Profile:
N/A
China Rohs Regulation:
X
Contacts Type And Composition:
1 NO
Device Short Name:
9001SK
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/4X/6/12/13
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Toxic Heavy Metal Free:
Yes
Product Or Component Type:
push-button
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Operator Additional Information:
snap-in plastic
Mercury Free:
Yes
Type Of Operator:
spring return
Sustainable Offer Status:
Green Premium product
Cap/Operator Or Lens Colour:
red
Operator Profile:
mushroom Ø 35 mm
Bezel Material:
plastic
Environmental Disclosure:
EnvPEP120817EN
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Range Of Product:
Harmony 9001SK
Contact Operation:
standard
Rohs Exemption Information:
Yes
Device Presentation:
complete product
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Size:
30 mm
Operator Profile:
red mushroom Ø 35 mm
Warranty:
18 months
Ip Degree Of Protection:
IP66
Reach Free Of Svhc:
Yes
Standards:
UL 508 || EN/IEC 60947-1 || JIS C 4520 || EN/IEC 60947-5-4 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || JIS C 852
Catalog:
View
Datasheet:
View
