Schneider Electric

Schneider Electric 9001SKS53FBH13 Selector Switch 600Vac 10A 30Mm Sk

(No reviews yet) Write a Review
SKU:
9001SKS53FBH13
UPC:
785901044055
Condition:
New
Warranty:
18 months
Mercury Free:
Yes
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Operator Position Information:
3 positions
Contacts Type And Composition:
1 C/O
Device Short Name:
9001SK
Cam Profile:
3
Operator Profile:
long handle
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Reach Free Of Svhc:
Yes
Protective Treatment:
TC
Bezel Material:
plastic
Range Of Product:
Harmony 9001SK
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Product Compatibility:
9001KA1 side 1 or 2
Operator Profile:
black long handle
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Ambient Air Temperature For Operation:
-25-70 °C
China Rohs Regulation:
X
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/4X/6/12/13
Type Of Operator:
spring return
Circularity Profile:
N/A
Rohs Exemption Information:
Yes
Product Certifications:
CSA LR24590 class 3211 03 || CE || UL listed file E42259 CCN NKCR
Ip Degree Of Protection:
IP66 IEC 60529
Ambient Air Temperature For Storage:
-40-70 °C
Type Of Operator:
to centre spring return
Cap/Operator Or Lens Colour:
black
Product Or Component Type:
selector switch
Environmental Disclosure:
ENVPEP120820EN
Return:
both sides to centre
Sustainable Offer Status:
Green Premium product
Toxic Heavy Metal Free:
Yes
Device Presentation:
complete product
Electrical Shock Protection Class:
class II IEC 61140
Size:
30 mm
Mounting Diameter:
30 mm
Brochure:
View
Datasheet:
View
$138.00

Description

This Harmony 9001SK, black selector switch with long handle and C cam has 3 positions, operates with spring return from left and right to center position. It has a double insulated plastic bezel and uses screw-clamp terminals. This selector switch with long handle provides a versatile interface for controlling your machines. It is easily installed into a standard 30mm diameter panel cut-outs and connected to control circuits with simple screw-clamp connections. It provides an effective manner to set your machine in various operating modes. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Impact and corrosion resistant plastic body ensures product continues to operate even after severe accidents.
