Schneider Electric 9001SKT1R31 Pilot Light 120Vac 30Mm Sk +Options

Schneider Electric 9001SKT1R31 Pilot Light 120Vac 30Mm Sk +Options

Schneider Electric
SKU:
9001SKT1R31
|
UPC:
3.38912E+12
Availability:
Contact us to confirm availability and lead times.
$197.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This red pilot light is part of the range of control and signaling units, Harmony 9001SK diameter 30mm plastic. It has a double insulated bezel and is delivered with push to test operator and plastic fresnel lens. It is supplied via internal transformer with 110V to 120V AC. Thanks to its double insulated bezel it is adapted for applications requiring a high resistance to corrosion. It is easily installed into a standard 30mm diameter panel cut-outs. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.
Additional Information
Contacts Type And Composition:
1 C/O
Light Block Supply:
via transformer 110 V AC 50/60 Hz || via transformer 120 V AC 50/60 Hz
Mercury Free:
Yes
Protective Treatment:
TC
Mounting Diameter:
30 mm
Range Of Product:
Harmony 9001SK
Supply Frequency:
50...60 Hz
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Operating Mode:
push-to-test
Rohs Exemption Information:
Yes
Sustainable Offer Status:
Green Premium product
Ip Degree Of Protection:
IP66
California Proposition 65:
WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr
Lens Type:
fresnel plastic
Size:
30 mm
[Us] Rated Supply Voltage:
110...120 V
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Environmental Disclosure:
ENVPEP121111EN
Circularity Profile:
ENVEOLI121107EN
China Rohs Regulation:
X
Product Or Component Type:
push-to-test pilot light
Light Block Supply:
via integral transformer
Cap/Operator Or Lens Colour:
red
Shape Of Signaling Unit Head:
round
Bulb Base:
BA 9s
Light Source:
incandescent bulb
Warranty:
18 months
Reach Free Of Svhc:
Yes
Toxic Heavy Metal Free:
Yes
Lens Type:
fresnel
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Bezel Material:
plastic
Lens Material:
polycarbonate
Brochure:
View
Catalog:
View
Datasheet:
View
QN-QUOTE-REQUEST:
true
