Schneider Electric 9050JCK60V24 Timer Relay 240Vac 10Amp +Options
Schneider Electric
$152.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
9050JCK plug in timers are designed to provide low cost timing in a plug in housing. This timer has an on delay timing mode. When the input voltage is applied, the time delay begins. Relay contacts change state after time delay is complete. When the input voltage is removed, contacts return to their shelf state. The timing range of 0.5 seconds to 999 hours is easily adjustable with thumb wheels on the top of the timer. This plug in timer plugs into an 8501NR51 or 8501NR52 relay socket. These relay sockets can be mounted on 35 mm DIN 3 mounting track or directly to a panel. All wiring is made to the relay socket. The DPDT contacts are rated 10 amperes resistive at 120 VAC, 240 VAC and 30 VDC, 3 amperes inductive at 120 VAC, 240 VAC and 30 VDC, 1/3 HP on the NC contacts at 120 VAC and 240 VAC, 1/2 HP on the NO contacts at 120 VAC and 240 VAC. This plug in timer is powered up with 240 VAC 50/60 Hz. 9050JCK plug in timers are UL listed when the proper 8501NR relay socket is used, UL component recognized and CSA certified.
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Circularity Profile:
- ENVEOLI1406037EN
- Range Of Product:
- 9050JCK
- Time Delay Range:
- 0.1...99.9 h || 1...999 h || 0.05...9.99 s || 1...999 min || 1...999 s || 0.1...99.9 s
- Reach Free Of Svhc:
- Yes
- Height:
- 60 mm
- Hold-In Power Consumption In Va:
- 3.2-3.2 VA
- Product Certifications:
- UL Recognized || UL Listed || CE
- Shape Of Pin:
- tubular
- Time Delay Type:
- on-delay
- Environmental Disclosure:
- ENVPEP1406037EN
- Mercury Free:
- Yes
- Product Compatibility:
- 8501NR52 || 8501NR51
- Width:
- 44 mm
- Product Or Component Type:
- timer
- Contacts Type And Composition:
- 2 NO + 2 NC
- Line Rated Current:
- 0.416666666666667
- China Rohs Regulation:
- X
- Depth:
- 91 mm
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Switch Function:
- DPDT
- Warranty:
- 18 months
- [Uc] Control Circuit Voltage:
- 240 V AC
- Sustainable Offer Status:
- Green Premium product
- Toxic Heavy Metal Free:
- Yes
- Ambient Air Temperature For Operation:
- -18-122 °F
- Rohs Exemption Information:
- Yes
- Pin Number:
- 8
- Contacts Material:
- silver nickel
- Maximum Switching Voltage:
- 240 V AC
- Mounting Support:
- socket
