Schneider Electric ABL8RPS24030 Univ.Power Sup 1P 24V 3A

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric ABL8RPS24030 Univ.Power Sup 1P 24V 3A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ABL8RPS24030

UPC:

3389119405607

MPN:

Condition:

New

Output Voltage:

24 V DC

Connections - Terminals:

screw type terminals 3 x 0.5...3 x 4 mm², AWG 22...AWG 12) input connection || screw type terminals 1 x 0.5...1 x 4 mm², AWG 22...AWG 12) input ground connection || screw type terminals 4 x 0.5...4 x 4 mm², AWG 22...AWG 12) output connection || screw

Power Supply Type:

regulated switch mode

Depth:

125 mm

Efficiency:

0.87

Inrush Current:

30 A

Mounting Support:

35 x 15 mm symmetrical DIN rail || 35 x 7.5 mm symmetrical DIN rail

Dielectric Strength:

3500 V with between input and ground || 4000 V with between input and output || 500 V with between output and ground

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Environmental Disclosure:

ENVPEP061201EN

Environmental Characteristic:

EMC IEC 61000-6-1 || EMC IEC 61000-6-3 || EMC IEC 61000-6-2 || EMC IEC 61000-6-4 || EMC EN/IEC 61204-3 || safety IEC 60950-1 || safety EN/IEC 61204-3

Operating Position:

vertical

Power Dissipation In W:

7.8 W

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Ambient Air Temperature For Operation:

50-60 °C with derating factor mounting position A < 6561.68 ft (2000 m) || -25-50 °C without derating mounting position A < 6561.68 ft (2000 m)

Marking:

CE

Sustainable Offer Status:

Green Premium product

Rohs Exemption Information:

Yes

Width:

45 mm

Permissible Temporary Current Boost:

1.5 x In for 4 s)

Product Or Component Type:

power supply

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Provided Equipment:

power factor correction filter IEC 61000-3-2

Standards:

CSA C22.2 No 60950-1 || UL 508 || EN/IEC 62368-1

Efficiency At Full Load:

170...550 V AC || 85...132 V AC

Power Supply Output Current:

0.125

Pvc Free:

Yes

Status Led:

1 LED (green and red) output voltage || 1 LED (green, red and orange) output current

Output Voltage Limits:

24...28.8 V adjustable

Range Of Product:

Modicon Power Supply

Operating Altitude:

6561.68 ft (2000 m)

China Rohs Regulation:

X

Anti-Harmonic Filter:

low frequency harmonic currents

Height:

125 mm

Supply:

SELV IEC 60950-1 || SELV IEC 60204-1 || SELV IEC 60364-4-41

Power Factor:

0.51 at 240 V AC || 0.59 at 120 V AC

Output Protection Type:

against overload manual or automatic reset || against overvoltage 30...32 V, manual reset || against short-circuits manual or automatic reset || against undervoltage tripping if U < 21.6 V || thermal automatic reset

Warranty:

18 months

Kw Rating:

72 W

Net Weight:

0.3 kg

Mercury Free:

Yes

Ip Degree Of Protection:

IP20 conforming to IEC 60529

Circularity Profile:

ENVEOLI120913EN

Input Voltage:

100...120 V AC single phase N-L1 || 200...500 V AC phase to phase L1-L2

Output Coupling:

parallel || series

Product Certifications:

cCSAus || EAC || UL || RCM || KC
