Schneider Electric

Schneider Electric BRS39AW271ACA Vrdm3910/50Lwc Eoip41 Oo D9O 73 Obboooo

SKU:

BRS39AW271ACA

UPC:

3606485150192

MPN:

Condition:

New

China Rohs Regulation:

X

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Service Life In Hours:

20000 h bearing)

Resistance:

5.8 Ohm winding)

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Length:

141 mm

Mounting Holes Diameter:

6.5 mm

Speed Feedback Resolution:

10000 points/turn

Shaft Diameter:

9.5 mm

Vibration Resistance:

20 m/s² maximum || A IEC 60034-14

Maximum Axial Force Fa:

175 N tensile force) || 30 N force pressure)

Maximum Radial Force Fr:

100 N first shaft end) || 50 N second shaft end)

Maximum Mechanical Speed:

3000 rpm

Number Of Motor Poles:

6

Product Or Component Type:

motion control motor

Range Compatibility:

Lexium SD3

Device Short Name:

BRS3

Circle Diameter Of The Mounting Holes:

98.99 mm

Line Rated Current:

0.0833333333333333

Mercury Free:

Yes

Shaft Length:

30 mm

Supply Voltage Limits:

230-230 V AC || 325-325 V DC

Time Constant:

9 ms

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Holding Torque:

4.52 N.m

Sustainable Offer Status:

Green Premium product

Shaft End:

untapped

Rotor Inertia:

2.2 kg.cm²

Relative Humidity:

15-85 % without condensation

Type Of Cooling:

natural convection

Motor Type:

3-phase stepper motor

Temperature Class:

F winding IEC 60034-1

Angular Acceleration:

200000 rad/s²

Rohs Exemption Information:

Yes

Continuous Stall Torque:

3.82 N.m

Ip Degree Of Protection:

shaft bushing IP41 IEC 60034-5 || total except shaft bushing IP56 IEC 60034-5

Holding Brake:

without

Ambient Air Temperature For Operation:

-25-40 °C

Centring Collar Diameter:

73 mm

Feedback Type:

single turn encoder

Second Shaft:

without second shaft end

Maximum Starting Frequency:

5.3 kHz

Nominal Torque:

4 N.m

Net Weight:

3.2 kg

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Peak Stall Torque:

3.82 N.m

Accuracy Error:

+/- 6 arc min

Mounting Support:

flange

Resolution:

1000 points/turn || 1.8 °, 0.9 °, 0.72 °, 0.36 °, 0.18 °, 0.09 °, 0.072 °, 0.036 ° step angle || 200, 400, 500, 1000, 2000, 4000, 5000, 10000 steps number of full steps per revolution

Standards:

IEC 60072-1 || IEC 50347

Environmental Disclosure:

ENVPEP111101EN

Warranty:

18 months

Circularity Profile:

N/A

Number Of Mounting Holes:

4

Pvc Free:

Yes

Operating Altitude:

<= 3280.84 ft (1000 m) without power derating

Electrical Connection:

connector

Centring Collar Depth:

2 mm

Ambient Air Temperature For Storage:

-25-70 °C

Motor Flange Size:

85 mm
