Schneider Electric EDB14050SA Miniature Circuit Breaker 277V 50A
Schneider Electric
$905.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric EDB14050SA Miniature Circuit Breaker 277V 50A
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 50A, 1 pole, and has a operating voltage of 277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
- Depth:
- 4.05 in
- Width:
- 1.96 in
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- [Ue] Rated Operational Voltage:
- 277 V AC
- Local Signalling:
- trip indicator
- Holding Current:
- 630 A
- Product Certifications:
- cULus || IEC
- Number Of Spaces:
- 2
- Trip Unit Technology:
- thermal-magnetic
- Trip Unit Rating:
- 1800-1800 A
- Protection Type:
- short-circuit || overload
- Net Weight:
- 2 lb(US)
- Number Of Poles:
- 1
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Device Short Name:
- EDB
- Breaking Capacity:
- 18 kA 277 V AC || 18 kA 240 V AC || 25 kA 120 V AC || 18 kA 120/240 V AC
- Mercury Free:
- Yes
- Module Type:
- E-Frame
- Warranty:
- 18 months
- Breaking Capacity Code:
- D
- Number Of Spaces Required:
- 2
- Ambient Air Temperature For Operation:
- 40 °C
- Mounting Mode:
- bolt-on
- Device Composition:
- shunt trip
- Product Or Component Type:
- miniature circuit-breaker
- Circuit Breaker Application:
- HID rated || HACR rated
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Electrical Connection:
- lugs aluminium
- Rohs Exemption Information:
- Yes
- Height:
- 5.66 in
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Line Rated Current:
- 50 A
- Product Destination:
- NF panelboard
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
