Schneider Electric EDB14060 Miniature Circuit Breaker 277V 60A
Schneider Electric
$150.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 60A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
- Ambient Air Temperature For Operation:
- 40 °C
- Warranty:
- 18 months
- Trip Unit Technology:
- thermal-magnetic
- Product Destination:
- NF panelboard
- Protection Type:
- overload || short-circuit
- Mercury Free:
- Yes
- Depth:
- 4.05 in
- Product Or Component Type:
- miniature circuit-breaker
- Net Weight:
- 2 lb(US)
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Number Of Spaces Required:
- 1
- Number Of Poles:
- 1
- Module Type:
- E-Frame
- Number Of Spaces:
- 1
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Circuit Breaker Application:
- HACR rated
- Height:
- 5.66 in
- Breaking Capacity:
- 18 kA 277 V AC || 18 kA 240 V AC || 25 kA 120 V AC || 18 kA 120/240 V AC
- Rohs Exemption Information:
- Yes
- Mounting Mode:
- bolt-on
- Electrical Connection:
- lugs aluminium
- Local Signalling:
- trip indicator
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- [Ue] Rated Operational Voltage:
- 277 V AC
- Holding Current:
- 630 A
- Device Short Name:
- EDB
- Trip Unit Rating:
- 1800-1800 A
- Line Rated Current:
- 60 A
- Breaking Capacity Code:
- D
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Width:
- 0.98 in
- Product Certifications:
- IEC || cULus
