Schneider Electric EDB24090 Miniature Circuit Breaker 480Y/277V 90A
Schneider Electric
$1,134.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric EDB24090 Miniature Circuit Breaker 480Y/277V 90A
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 90A, 2 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 1000A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 2300A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Net Weight:
- 3 lb(US)
- Number Of Poles:
- 2
- Warranty:
- 18 months
- Mounting Mode:
- bolt-on
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Number Of Spaces Required:
- 2
- Depth:
- 4.05 in
- Width:
- 1.96 in
- Breaking Capacity Code:
- D
- Breaking Capacity:
- 18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Holding Current:
- 1000 A
- Device Short Name:
- EDB
- Product Or Component Type:
- miniature circuit-breaker
- Module Type:
- E-Frame
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Ambient Air Temperature For Operation:
- 40 °C
- Trip Unit Technology:
- thermal-magnetic
- Product Certifications:
- cULus
- Number Of Spaces:
- 2
- Rohs Exemption Information:
- Yes
- Local Signalling:
- trip indicator
- Line Rated Current:
- 90 A
- Electrical Connection:
- lugs aluminium
- Height:
- 5.66 in
- Protection Type:
- short-circuit || overload
- Product Destination:
- NF panelboard
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC
- Trip Unit Rating:
- 2300-2300 A
- Circuit Breaker Application:
- HACR rated
