Schneider Electric EDB26020 Miniature Circuit Breaker 600V 20A

(No reviews yet) Write a Review
SKU:
EDB26020
UPC:
785901234296
Condition:
New
Rohs Exemption Information:
Yes
Trip Unit Rating:
875-875 A
Range Of Product:
125 A Frame EDB-EGB-EJB
Width:
1.96 in
Module Type:
E-Frame
Circuit Breaker Application:
HACR rated
Mercury Free:
Yes
Depth:
4.05 in
Number Of Spaces Required:
2
Net Weight:
3 lb(US)
Protection Type:
short-circuit || overload
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Breaking Capacity Code:
D
Line Rated Current:
20 A
Awg Gauge:
AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
Electrical Connection:
lugs aluminium
Warranty:
18 months
Local Signalling:
trip indicator
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Device Short Name:
EDB
Number Of Spaces:
2
Product Destination:
NF panelboard
Trip Unit Technology:
thermal-magnetic
Height:
5.66 in
Product Certifications:
cULus
[Ue] Rated Operational Voltage:
600Y/347 V AC
Holding Current:
270 A
Breaking Capacity:
14 kA 600Y/347 V AC
Product Or Component Type:
miniature circuit-breaker
Mounting Mode:
bolt-on
Number Of Poles:
2
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Ambient Air Temperature For Operation:
40 °C
$536.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 20A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
