Schneider Electric EDB26070 Miniature Circuit Breaker 600V 70A

(No reviews yet) Write a Review
SKU:
EDB26070
UPC:
7.85901E+11
Condition:
New
Width:
1.96 in
Height:
5.66 in
Product Certifications:
cULus
Product Or Component Type:
miniature circuit-breaker
Mounting Mode:
bolt-on
Number Of Spaces Required:
2
Number Of Spaces:
2
Local Signalling:
trip indicator
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Range Of Product:
125 A Frame EDB-EGB-EJB
Rohs Exemption Information:
Yes
Mercury Free:
Yes
Product Destination:
NF panelboard
Trip Unit Rating:
1800-1800 A
Electrical Connection:
lugs aluminium
Module Type:
E-Frame
[Ue] Rated Operational Voltage:
600Y/347 V AC
Circuit Breaker Application:
HACR rated
Depth:
4.05 in
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Breaking Capacity:
14 kA 600Y/347 V AC
Line Rated Current:
70 A
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Breaking Capacity Code:
D
Protection Type:
overload || short-circuit
Ambient Air Temperature For Operation:
40 °C
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Holding Current:
630 A
Trip Unit Technology:
thermal-magnetic
Device Short Name:
EDB
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Warranty:
18 months
Net Weight:
3 lb(US)
Number Of Poles:
2
  • Schneider Electric EDB26070 Miniature Circuit Breaker 600V 70A
  • Schneider Electric EDB26070 Miniature Circuit Breaker 600V 70A
$1,134.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
