Schneider Electric EDB34020LH Miniature Circuit Breaker 480Y/277V 20A

(No reviews yet) Write a Review
SKU:
EDB34020LH
UPC:
785901638582
Condition:
New
Device Short Name:
EDB
Height:
5.66 in
Breaking Capacity:
18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
Line Rated Current:
20 A
Product Or Component Type:
miniature circuit-breaker
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Number Of Poles:
3
[Ue] Rated Operational Voltage:
480Y/277 V AC
Trip Unit Technology:
thermal-magnetic
Number Of Spaces Required:
3
Electrical Connection:
high ampere lugs aluminium
Net Weight:
4 lb(US)
Product Destination:
NF panelboard
Local Signalling:
trip indicator
Depth:
4.05 in
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Number Of Spaces:
3
Rohs Exemption Information:
Yes
Holding Current:
270 A
Circuit Breaker Application:
HID rated || HACR rated
Protection Type:
overload || short-circuit
Module Type:
E-Frame
Range Of Product:
125 A Frame EDB-EGB-EJB
Mounting Mode:
bolt-on
Trip Unit Rating:
875-875 A
Ambient Air Temperature For Operation:
40 °C
Width:
2.94 in
Product Certifications:
cULus
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Mercury Free:
Yes
Breaking Capacity Code:
D
Warranty:
18 months
$803.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 20A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes high amp lugs. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
