Schneider Electric EDB34040CA Miniature Circuit Breaker 480Y/277V 40A

Schneider Electric EDB34040CA Miniature Circuit Breaker 480Y/277V 40A

Schneider Electric
SKU:
EDB34040CA
|
UPC:
785901490357
Availability:
Contact us to confirm availability and lead times.
$803.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 40A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 50 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Breaking Capacity:
18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
Mounting Mode:
bolt-on
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
[Ue] Rated Operational Voltage:
480Y/277 V AC
Module Type:
E-Frame
Number Of Poles:
3
Ambient Air Temperature For Operation:
50 °C
Range Of Product:
125 A Frame EDB-EGB-EJB
Circuit Breaker Application:
HACR rated || HID rated
Trip Unit Rating:
1800-1800 A
Warranty:
18 months
Rohs Exemption Information:
Yes
Electrical Connection:
lugs aluminium
Protection Type:
overload || short-circuit
Number Of Spaces Required:
3
Product Certifications:
cULus
Product Or Component Type:
miniature circuit-breaker
Device Short Name:
EDB
Depth:
4.05 in
Breaking Capacity Code:
D
Holding Current:
630 A
Eu Rohs Directive:
Compliant with Exemptions
Line Rated Current:
40 A
Mercury Free:
Yes
Height:
5.66 in
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Local Signalling:
trip indicator
Number Of Spaces:
3
Product Destination:
NF panelboard
Trip Unit Technology:
thermal-magnetic
Net Weight:
4 lb(US)
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Width:
2.94 in
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
