Schneider Electric EDB34060AABASA Miniature Circuit Breaker 480Y/277V 60A
Schneider Electric
$1,736.00
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 60A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes an auxiliary switch, alarm switch and a shunt trip. This breaker was calibrated for 40 degrees C. HACR rated.
- Product Certifications:
- cULus
- Local Signalling:
- trip indicator
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Number Of Poles:
- 3
- Warranty:
- 18 months
- Product Or Component Type:
- miniature circuit-breaker
- Number Of Spaces:
- 4
- Trip Unit Technology:
- thermal-magnetic
- Module Type:
- E-Frame
- Depth:
- 4.05 in
- Height:
- 5.66 in
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Breaking Capacity Code:
- D
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Ambient Air Temperature For Operation:
- 40 °C
- Eu Rohs Directive:
- Compliant with Exemptions
- Line Rated Current:
- 60 A
- Protection Type:
- overload || short-circuit
- Device Short Name:
- EDB
- Trip Unit Rating:
- 1800-1800 A
- Mounting Mode:
- bolt-on
- Width:
- 3.92 in
- Circuit Breaker Application:
- HACR rated
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC
- Mercury Free:
- Yes
- Electrical Connection:
- lugs aluminium
- Device Composition:
- auxiliary switch || alarm switch || shunt trip
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Number Of Spaces Required:
- 4
- Holding Current:
- 630 A
- Breaking Capacity:
- 18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
- Rohs Exemption Information:
- Yes
- Net Weight:
- 4 lb(US)
- Product Destination:
- NF panelboard
