Schneider Electric EDB34070AABASA Miniature Circuit Breaker 480Y/277V 70A
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes an auxiliary switch, alarm switch and a shunt trip. This breaker was calibrated for 40 degrees C. HACR rated.
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Circuit Breaker Application:
- HACR rated
- Net Weight:
- 4 lb(US)
- Mercury Free:
- Yes
- Product Destination:
- NF panelboard
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Number Of Spaces Required:
- 4
- Warranty:
- 18 months
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC
- Number Of Poles:
- 3
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Eu Rohs Directive:
- Compliant with Exemptions
- Breaking Capacity:
- 18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
- Trip Unit Technology:
- thermal-magnetic
- Depth:
- 4.05 in
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Line Rated Current:
- 70 A
- Trip Unit Rating:
- 1800-1800 A
- Protection Type:
- short-circuit || overload
- Breaking Capacity Code:
- D
- Module Type:
- E-Frame
- Product Certifications:
- cULus
- Product Or Component Type:
- miniature circuit-breaker
- Device Composition:
- alarm switch || shunt trip || auxiliary switch
- Number Of Spaces:
- 4
- Holding Current:
- 630 A
- Mounting Mode:
- bolt-on
- Electrical Connection:
- lugs aluminium
- Device Short Name:
- EDB
- Ambient Air Temperature For Operation:
- 40 °C
- Width:
- 3.92 in
- Local Signalling:
- trip indicator
- Height:
- 5.66 in
- Catalog:
- View
- Datasheet:
- View
