Schneider Electric EDB34070CA Miniature Circuit Breaker 480Y/277V 70A
Schneider Electric
$1,093.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric EDB34070CA Miniature Circuit Breaker 480Y/277V 70A
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 70A, 3 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 50 degrees C. HACR rated.
- Awg Gauge:
- AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
- Circuit Breaker Application:
- HACR rated
- Warranty:
- 18 months
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Product Destination:
- NF panelboard
- Height:
- 5.66 in
- Mercury Free:
- Yes
- Range Of Product:
- 125 A Frame EDB-EGB-EJB
- Net Weight:
- 4 lb(US)
- [Ue] Rated Operational Voltage:
- 480Y/277 V AC
- Breaking Capacity Code:
- D
- Product Certifications:
- cULus
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Rohs Exemption Information:
- Yes
- Depth:
- 4.05 in
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Device Short Name:
- EDB
- Local Signalling:
- trip indicator
- Module Type:
- E-Frame
- Line Rated Current:
- 70 A
- Number Of Spaces Required:
- 3
- Product Or Component Type:
- miniature circuit-breaker
- Trip Unit Rating:
- 1800-1800 A
- Trip Unit Technology:
- thermal-magnetic
- Width:
- 2.94 in
- Mounting Mode:
- bolt-on
- Electrical Connection:
- lugs aluminium
- Tightening Torque:
- 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
- Holding Current:
- 630 A
- Number Of Poles:
- 3
- Protection Type:
- overload || short-circuit
- Number Of Spaces:
- 3
- Ambient Air Temperature For Operation:
- 50 °C
- Breaking Capacity:
- 18 kA 277 V AC || 25 kA 240 V AC || 18 kA 480Y/277 V AC || 25 kA 120 V AC || 25 kA 120/240 V AC
