Schneider Electric EDB36050 Miniature Circuit Breaker 600V 50A

Schneider Electric EDB36050 Miniature Circuit Breaker 600V 50A

Schneider Electric
SKU:
EDB36050
|
UPC:
785901234807
Availability:
Contact us to confirm availability and lead times.
$669.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 50A, 3 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Electrical Connection:
lugs aluminium
Product Destination:
NF panelboard
Net Weight:
4 lb(US)
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Line Rated Current:
50 A
Width:
2.94 in
Mounting Mode:
bolt-on
Device Short Name:
EDB
Trip Unit Technology:
thermal-magnetic
Range Of Product:
125 A Frame EDB-EGB-EJB
Breaking Capacity:
14 kA 600Y/347 V AC
Circuit Breaker Application:
HACR rated
Breaking Capacity Code:
D
Mercury Free:
Yes
Number Of Spaces Required:
3
Height:
5.66 in
Ambient Air Temperature For Operation:
40 °C
Number Of Spaces:
3
Module Type:
E-Frame
Number Of Poles:
3
Rohs Exemption Information:
Yes
Product Or Component Type:
circuit-breaker
Local Signalling:
trip indicator
Protection Type:
short-circuit || overload
Trip Unit Rating:
1800-1800 A
Product Certifications:
cULus
Holding Current:
630 A
Warranty:
18 months
[Ue] Rated Operational Voltage:
600Y/347 V AC
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Depth:
4.05 in
