Schneider Electric EGB26020 Miniature Circuit Breaker 600V 20A

Schneider Electric EGB26020 Miniature Circuit Breaker 600V 20A

Schneider Electric
SKU:
EGB26020
|
UPC:
7.85901E+11
Availability:
Factory stock
$604.20
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 20A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 65 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
Additional Information
Line Rated Current:
20 A
Height:
5.66 in
Breaking Capacity:
18 kA 600Y/347 V AC
Trip Unit Rating:
875-875 A
Product Destination:
NF panelboard
Product Or Component Type:
circuit-breaker
[Ue] Rated Operational Voltage:
600Y/347 V AC
Number Of Poles:
2
Width:
1.96 in
Range Of Product:
125 A Frame EDB-EGB-EJB
Module Type:
E-Frame
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Awg Gauge:
AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
Product Certifications:
cULus
Circuit Breaker Application:
HACR rated
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Depth:
4.05 in
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Trip Unit Technology:
thermal-magnetic
Local Signalling:
trip indicator
Ambient Air Temperature For Operation:
40 °C
Number Of Spaces Required:
2
Mounting Mode:
bolt-on
Device Short Name:
EGB
Holding Current:
270 A
Warranty:
18 months
Rohs Exemption Information:
Yes
Mercury Free:
Yes
Number Of Spaces:
2
Electrical Connection:
lugs aluminium
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Net Weight:
3 lb(US)
Breaking Capacity Code:
G
Protection Type:
overload || short-circuit
